Channel 672 - Vinyl

  • Bim, Content, Object, Component, bimstore, Revit, BLÜCHER®, Drainage, Drain, End, Outlet, Center, Channel, 672
  • Bim, Content, Object, Component, bimstore, Revit, BLÜCHER®, Drainage, Drain, End, Outlet, Center, Channel, 672
  • Bim, Content, Object, Component, bimstore, Revit, BLÜCHER®, Drainage, Drain, End, Outlet, Center, Channel, 672
  • Bim, Content, Object, Component, bimstore, Revit, BLÜCHER®, Drainage, Drain, End, Outlet, Center, Channel, 672
SketchfabSketchfab
  • Views 37.7k
  • Comments 0
  • Rating3.7 / 5
    Rate this product
    1/5 Rating1/5 Rating2/5 Rating2/5 Rating3/5 Rating3/5 Rating4/5 Rating4/5 Rating5/5 Rating5/5 Rating

BS1192:4

Compliant

BSB

Compliant

Object Data

2 Revision

Last Updated

25/11/2021

Available for:
  • Logo: Autodesk Revit

Drains & Upper Parts with Rectangular Top (Channels) : Channel - Vinyl : 672CH / 672DH / 672DK / 672EK / 672FK

  • The channel is made from 1,5 mm acid-pickled stainless steel.

  • Designed in accordance with standard EN1253.

  • The longitudinal fall is 1% and the cross fall corresponds to 160°-170°.

  • Floor: Vinyl

  • Stainless steel: AISI304/EN1.4301

  • Width: 150, 200, 300 and 400 mm.

  • Length: 1000 mm up to 6000 mm.

Select the product(s) based on outside (visible) dimension, flow rate, and / or item number, to upload in your project.

  • Horizontal and Vertical outlet, height adjustable, 75 and 110 mm
  • With and without membrane and for vinyl floors.
  • The product is made from 2 mm acid-pickled stainless steel.
  • 4 Grating options load class up to 20.000 kg
  • Designed in accordance with EN1253.

Key Component Features:

  • User selectable Channel
  • User selectable Gratings
  • User selectable Lower Parts
  • User selectable Watertrap
  • User selectable Filter Basket
  • 360 degree Lower Part
  • Height adjustment
  • Automated product codes
  • Pre-selected concrete cut out / base concrete slab option for installation purpose

Products : 672CH, 672DH, 672DK, 672EK, 672FK

Search Opt.: blucher
