Elite Cyl Heat Pump - Standard

by UK Cylinders

Download Add to collection

Description

ELITE CYL Heat pump

Our cylinders are manufactured to the highest quality in our UK factory by the best manufacturing specialists.

The Elite Cyl heat pump cylinder is designed for maximum performance. The Elite Cyl is fitted and supplied with all the required components and controls to provide seamless compatibility with your chosen heat pump.

Click here to visit UK Cylinders for more information.

Object Data

2 Revision

Last Updated

23/01/2025

Available Software

BS1192:4

Compliant

BSB

Compliant

EPD

Not Available

Accompanying literature

Object User Guide

Product Literature

Product Data Sheet

Object metadata

_AuthorBS
_Authorized Bybimstore
_Bim Spec Guid1
_BS Bible Version17
_Created Bywww.bimstore.co/
_Current Revision1
_Distributed Bywww.bimstore.co/
_Object User Guidewww.bimstore.co/products/elite-cyl-heat-pump-standard/document/object-user-guide
Accessibility Performancen/a
Assembly CodeD3060100
Asset TypeFixed
B715 mm
BC1190 mm
BC2265 mm
BIM Object NameUKCylinders_HeatPump_EliteCyl
Body Radius270 mm
C0 mm
Casing Collar GreyUK Cylinders - Casing - Grey
Casing Collar RedUK Cylinders - Casing - Red
Casing GreyUK Cylinders - Casing - Grey
Casing MaterialUK Cylinders - Casing - Silver
Classification NameUniclass 2015
Classification ValuePr_60_50_20_27
Code Performancen/a
ColorSilver
Constituentsn/a
Control PanelUK Cylinders - Control Panel - Black Screen
Created Bysales@ukcylinders.co.uk
Created On2024-03-22T09:00:00
D0 mm
Default Elevation0 mm
DescriptionAll our Universal heat pump cylinders feature a unique high flow, high gain, full bore coil design which we manufacture in house, to provide superior performance.
Diameter545 mm
Documentation Certificateswww.bimstore.co/products/elite-cyl-heat-pump-standard/document/product-certificates
Documentation Installation Guidewww.bimstore.co/products/elite-cyl-heat-pump-standard/document/installation-guide
Documentation Literaturewww.bimstore.co/products/elite-cyl-heat-pump-standard/document/product-literature
Documentation Maintenancewww.bimstore.co/products/elite-cyl-heat-pump-standard/document/maintenance-information
Documentation Technicalwww.bimstore.co/products/elite-cyl-heat-pump-standard/document/technical-data-sheet
Duration UnitYears
E180 mm
Expected Life0
F190 mm
FeaturesSupplied with high quality unvented components.
Finishn/a
Graden/a
Height945 mm
Ifc Export AsIfcSpaceHeater
Ifc Export TypeIfcSpaceHeaterType
Immersion Heater TopNo
KeynoteT32
ManufacturerUK Cylinders
Manufacturer NameUK Cylinders
MaterialDuplex Stainless Steel
ModelESHPD3120
Model NumberESHPD3120
Model Reference120L
NBS DescriptionDirect hot water storage cylinders
NBS Noten/a
NBS Object NameUK Cylinders - Direct hot water storage cylinders
NBS Office Master Tagn/a
NBS Reference90-15-35/310
Nominal Depth545 mm
Nominal Height945 mm
Nominal Length545 mm
Offset0 mm
Production Year2024
PTRVUK Cylinders - Casing - Brass
Referenced Standardn/a
Replacement Costn/a
Secondary ReturnNo
ShapeCylinder
Size945x545mm
Spare Partssales@ukcylinders.co.uk
Type Comments120L
Type Name120L
URLukcylinders.co.uk/
Warranty Description25 year cylinder warranty and 2 years parts warranty.
Warranty Duration Labor0
Warranty Duration Parts25
Warranty Duration UnitYears
Warranty Guarantor Laborsales@ukcylinders.co.uk
Warranty Guarantor Partssales@ukcylinders.co.uk
