Grace updates the cast iron column radiator to give a striking design that sits equally well in modern interiors and period properties.

Hip-level deep fluted column radiator with linear moulding and inclined feet. Staggered spacing between the columns adds extra interest to the side view.
Heat output per section: 141 Watts.

Object metadata

_Authorinfo@castrads.com
_Authorized Bybimstore
_Bim Spec Guid0
_BS Bible Version16
_Created Byinfo@castrads.com
_Current Revision1
_Distributed Bywww.bimstore.co/
_Object User Guidewww.bimstore.co/products/grace-6-column-760mm/document/object-user-guide
Accessibility Performancen/a
Assembly CodeG3040
Asset TypeFixed
BIM Object NameCastrads_CastIronRadiator_Grace6Column_760mm
Classification NameUniclass 2015
Classification ValuePr_70_60_36_73
Code Performancen/a
Colorn/a
Constituentsn/a
Created Byinfo@castrads.com
Created On2021-11-01T:09:00:00
DescriptionGrace updates the cast iron column radiator to give a striking design that sits equally well in modern interiors and period properties.
Documentation Certificateswww.bimstore.co/products/grace-6-column-760mm/document/product-certificates
Documentation Installation Guidewww.bimstore.co/products/grace-6-column-760mm/document/installation-guide
Documentation Literaturewww.bimstore.co/products/grace-6-column-760mm/document/product-literature
Documentation Maintenancewww.bimstore.co/products/grace-6-column-760mm/document/maintenance-information
Documentation Technicalwww.bimstore.co/products/grace-6-column-760mm/document/technical-data-sheet
Duration UnitYears
Expected Life0
Featuresn/a
Finishn/a
Graden/a
Heat Output Per Section BTU502
Heat Output Per Section W147
Ifc Export AsIfcSpaceHeater
Ifc Export TypeIfcSpaceHeaterTypeEnum.RADIATOR
KeynoteT
Leg Section Mass6.7
ManufacturerCastrads
Manufacturer NameCastrads
MaterialCast Iron
Maximum Middle Sections16
ModelGrace 6 Column
Model NumberGrace 6 Column
Model ReferenceGrace 6 Column
NBS DescriptionRadiators
NBS Noten/a
NBS Object NameCastrads - Radiators
NBS Office Master Tagn/a
NBS Reference90-40-35/405
Nominal Depth0.00 mm
Nominal Height0.00 mm
Nominal Length0.00 mm
Production Year2021
Radiator Depth250.00 mm
Radiator FinishCastrads_MidGreySparkle
Radiator Height760.00 mm
Radiator Length271.00 mm
Referenced StandardEN442
Replacement Costn/a
Section Internal Volume0.85 m³
Section Mass6
Section Spacing60.30 mm
Shapen/a
Sizen/a
Spare Partsinfo@castrads.com
Type CommentsGrace 6 Column
Type NameGrace 6 Column
URLwww.castrads.com/
Warranty Description10 Year Guarantee
Warranty Duration Labor0
Warranty Duration Parts10
Warranty Duration UnitYears
Warranty Guarantor Laborinfo@castrads.com
Warranty Guarantor Partsinfo@castrads.com
