TEMPESTA Shower System (268182431)

Object metadata

• _AuthorRL 171
• _Authorized Bybimstore
• _Bim Spec Guid0
• _BS Bible Version17
• _Created Bywww.bimstore.co/
• _Current Revision1
• _Distributed Bywww.bimstore.co/
• _Object User GuideTBC
• Accessibility Performancen/a
• Assembly CodeD2013
• Asset TypeFixed
• BIM Object NameGrohe_ShowerSystemWithThermostat_268182431
• Classification NameUniclass2015
• Classification ValueTBC
• CO2 Neutral ProductionGROHE is one of the first leading manufacturer within the sanitary industry having a CO2-neutral production.
• Code Performancen/a
• ColorTBC
• Constituentsn/a
• Cradle To Cradle Certificationn/a
• Created Byinfo-uk@grohe.com
• Created On2023-10-01T:09:00:00
• Default Elevation0 mm
• DescriptionShower System With Thermostat
• Dimensions Document Linkcdn.cloud.grohe.com/dimdraw/100000/100000/100000/100300/100320/100329/100329752/1280/100329752.jpg
• Documentation CertificatesTBC
• Documentation Installation GuideTBC
• Documentation LiteratureTBC
• Documentation MaintenanceTBC
• Documentation TechnicalTBC
• Duration UnitYears
• EcojoyNo
• Expected Life0
• Faucet MaterialGrohe-Chrome
• Featuresn/a
• Finishn/a
• Full Recyclability Of PlasticAll plastic components are fully recycable
• Graden/a
• GROHE Social Committmentgreen.grohe.com/social_engagement
• GROHE Sustainabilitygreen.grohe.com
• Ifc Export AsIfcPipeFitting
• Ifc Export TypeIfcPipeFittingType
• Installation Videon/a
• KeynoteN16
• ManufacturerGrohe
• Manufacturer NameGrohe
• Materialn/a
• ModelShower System With Thermostat
• Model Number268182431
• Model ReferenceShower System With Thermostat
• NBS DescriptionTBC
• NBS Noten/a
• NBS Object NameTBC
• NBS Office Master Tagn/a
• NBS ReferenceTBC
• Nominal Depth0 mm
• Nominal Height0 mm
• Nominal Length0 mm
• PQ Diagram Linkn/a
• Primary MaterialGrohe_Chrome
• Product Descriptionconsisting of: horizontal swivable 390 mm shower arm (14 047) exposed thermostat with Aquadimmer function centre distance 160 mm allows change between: head shower Tempesta 250 (26 666) spray pattern: Rain head shower with white rear cover with ball joint, rotation angle ± 10° hand shower Tempesta 110 (27 597) 2 spray patterns: Rain, Jet adjustable in height with gliding element Rotaflex TwistStop shower hose 1750 mm 1/2" x 1/2" (28 410) maximum flow rate (at 3 bar): 8.5 l/min GROHE TurboStat compact cartridge with wax thermoelement GROHE SafeStop safety button at 38°C GROHE SafeStop Plus optional temperature limiter at 43°C included GROHE SmartSwitch - easily rotate the dial to enjoy your preferred spray option GROHE DreamSpray perfect spray pattern GROHE FastFixation upper bracket, +40 / -100 mm height adjustable and up to 36 mm depth adjustable ShockProof silicone ring prevents damages caused by shower falling GROHE Long-Life finish SpeedClean anti-limescale system Inner WaterGuide for a longer life TwistStop to prevent hose from twisting suitable for instantaneous heaters from 18 kW/h minimum flow rate 7 l/min integrated flow elements for improved performance with higher pressure differences between hot and cold water supply professional exclusive
• Production Year2023
• Product Number268182431
• Product Short TextShower system 1/2" with thermostat 160 cc for wall mounting
• Product TypeShower System
• Referenced Standardn/a
• Replacement Costn/a
• Shapen/a
• Sizen/a
• Spare Partsinfo-uk@grohe.com
• Sustainability Awardgreen.grohe.com/awards
• Sustainability Reportgreen.grohe.com/reporting
• TPI Document Linkn/a
• Type CommentsShower System With Thermostat
• Type NameShower System With Thermostat
• URLwww.grohe.co.uk/en_gb/-268182431.html
• Warranty Descriptionn/a
• Warranty Duration Labor0
• Warranty Duration Parts0
• Warranty Duration UnitYears
• Warranty Guarantor Laborinfo-uk@grohe.com
• Warranty Guarantor Partsinfo-uk@grohe.com
