ZEDRA Single-lever sink mixer 1/2" (30368002)

Object metadata

• _AuthorSM 175
• _Authorized Bybimstore
• _Bim Spec Guid0
• _BS Bible Version17
• _Created Bywww.bimstore.co/
• _Current Revision1
• _Distributed Bywww.bimstore.co/
• _Object User Guidewww.bimstore.co/products/grohe-30368002/document/object-user-guide
• Accessibility Performancen/a
• Assembly CodeD2010
• Asset TypeFixed
• BIM Object NameGrohe_SingleLeverMixer_Zedra_30368002
• Classification NameUniclass2015
• Classification ValuePr_40_20_87_55
• CO2 Neutral ProductionGROHE is one of the first leading manufacturer within the sanitary industry having a CO2-neutral production.
• Code Performancen/a
• ColorChrome
• Constituentsn/a
• Cradle To Cradle Certificationn/a
• Created Byinfo-uk@grohe.com
• Created On2024-02-27T:09:00:00
• Default Elevation0 mm
• DescriptionSingle Lever Mixer
• Dimensions Document Linkcdn.cloud.grohe.com/dimdraw/100000/100000/100000/100100/100120/100121/100121409/1280/100121409.jpg cdn.cloud.grohe.com/dimdraw/100000/100000/100000/100300/100320/100326/100326759/1280/100326759.jpg
• Documentation Certificateswww.bimstore.co/products/grohe-30368002/document/product-certificates
• Documentation Installation Guidewww.bimstore.co/products/grohe-30368002/document/installation-guide
• Documentation Literaturewww.bimstore.co/products/grohe-30368002/document/product-literature
• Documentation Maintenancewww.bimstore.co/products/grohe-30368002/document/product-maintenance
• Documentation Technicalwww.bimstore.co/products/grohe-30368002/document/technical-data-sheet
• Duration UnitYears
• EcojoyNo
• EF000003Top/tap hole
• EF000139Other
• EF00170770 °C
• EF002149TRUE
• EF002286Hose (gland nut)
• EF002671Chrome
• EF007955FALSE
• EF011775EB
• EF011779FALSE
• EF011781not applicable
• EF0127535.50
• EF014578not applicable
• EF014591false
• EF016731Group I,<= 20 dB(A)
• EF020105No
• EF020780Single-grip
• EF020781Cartouche, ceramic
• EF020785Other
• EF020787Group II, <=30 dB(A)
• EF020789202
• EF020791Other
• EF020792FALSE
• EF020795Rotating, top
• EF020796388 mm
• EF020797213
• EF020799TRUE
• EF020800false
• EF020801FALSE
• EF020803false
• EF020804false
• EF020871false
• EF020872true
• EF020873false
• EF021652false
• EF021758false
• EF0218081-hole
• EF0218275.5
• EF0218350
• EF022042None
• EF022750Pipe
• EF023686not applicable
• EF023687TRUE
• EF023688Anti-splash jet nozzle
• EF023957TRUE
• EF025109Polished
• EF025247false
• EFDE0022None
• EFSE0002false
• Expected Life0
• Featuresn/a
• FinishChrome
• Full Recyclability Of PlasticAll plastic components are fully recycable
• Graden/a
• GROHE Social Committmentgreen.grohe.com/social_engagement
• GROHE Sustainabilitygreen.grohe.com
• Ifc Export AsIfcFlowTerminalType
• Ifc Export TypeIfcSanitaryTerminalTypeEnum.SINK
• Installation Videon/a
• KeynoteN13
• ManufacturerGrohe
• Manufacturer NameGrohe
• Materialn/a
• ModelSingle Lever Mixer
• Model Number30368002
• Model ReferenceSingle Lever Mixer
• NBS DescriptionTaps and water supply fittings for sinks
• NBS Noten/a
• NBS Object NameGrohe - Taps and water supply fittings for sinks
• NBS Office Master Tagn/a
• NBS Reference45-35-70/345
• Nominal Depth0 mm
• Nominal Height0 mm
• Nominal Length0 mm
• PQ Diagram Linkcdn.cloud.grohe.com/PQCharts/lores/3/303/original/30368002-pqchart-en_GB.svg
• Primary MaterialGrohe_Chrome
• Product Descriptionfor bar sinks single hole installation GROHE Long-Life finish GROHE SilkMove 35 mm ceramic cartridge pull-out spray with 3 spray types diverter: laminar spray/SpeedClean shower jet/GROHE Blade spray (reduced water consumption by up to 70 % and even stronger spray performance) stop function - pause button to stop the water flow automatic return to laminar spray adjustable flow rate limiter swivel tubular spout, swivel area 360° protected against backflow flexible connection hoses metal fixation set Lead and Nickel Free Inner Water Ways maximum flow rate (at 3 bar): 6 l/min
• Production Year2024
• Product Number30368002
• Product Short TextSingle-lever sink mixer 1/2"
• Product TypeSingle Lever Mixer
• Referenced Standardn/a
• Replacement Costn/a
• Shapen/a
• Sizen/a
• Spare Partsinfo-uk@grohe.com
• Sustainability Awardgreen.grohe.com/awards
• Sustainability Reportgreen.grohe.com/reporting
• Type CommentsSingle Lever Mixer
• Type NameZEDRA Single Lever Mixer (30368002)
• URLwww.grohe.co.uk/
• Warranty Descriptionn/a
• Warranty Duration Labor0
• Warranty Duration Parts0
• Warranty Duration UnitYears
• Warranty Guarantor Laborinfo-uk@grohe.com
• Warranty Guarantor Partsinfo-uk@grohe.com
