Air Curtain - IP2

Object metadata

• _AuthorAM
• _Authorized Bybimstore
• _Bim Spec Guid0
• _BS Bible Version16
• _Created Bywww.bimstore.co
• _Current Revision1
• _Distributed Bywww.bimstore.co
• _Object User Guidewww.bimstore.co/products/air-curtain-ip2/document/object-user-guide
• 1 L/1 RYes
• 2 L/2 RNo
• A1500.00 mm
• Accessibility Performancen/a
• Assembly CodeD3090400
• Asset TypeFixed
• BIM Object NameThermoscreens_MechanicalEquipment_AirCurtain_IP2
• Bracket Length740.00 mm
• Classification NameUniclass2015
• Classification ValuePr_70_60_36_02
• Code Performancen/a
• ColorRAL 9016
• Connection Offset Calc1420.00 mm
• Constituentsn/a
• Created Bysales@thermoscreens.com
• Created On2023-03-20 T09:00:00
• Default Elevation3000.00 mm
• Depth725.00 mm
• DescriptionAir curtain
• Documentation Certificateswww.bimstore.co/products/air-curtain-ip2/document/product-certificates
• Documentation Installation Guidewww.bimstore.co/products/air-curtain-ip2/document/installation-guide
• Documentation Literaturewww.bimstore.co/products/air-curtain-ip2/document/product-literature
• Documentation Maintenancewww.bimstore.co/products/air-curtain-ip2/document/maintenance-information
• Documentation Technicalwww.bimstore.co/products/air-curtain-ip2/document/technical-data-sheet
• Drop320.00 mm
• Duration UnitYear
• Expected Life0
• Featuresn/a
• Finishn/a
• Graden/a
• Heating Power0 kW
• Height275.00 mm
• Horizontal InstallationYes
• Ifc Export AsIfcUnitaryEquipmentType
• Ifc Export TypeAIRCONDITIONINGUNIT
• KeynoteU
• Length1500.00 mm
• ManufacturerThermoscreens
• Manufacturer NameThermoscreens
• Materialn/a
• Maximum Air Flow Rate14356 m3/h
• Maximum Power Consumption1.8 kW
• ModelIP2 L-1500-A-0 Simple RAL 9016
• Model NumberIP2 L-1500-A-0 Simple RAL 9016
• Model ReferenceThermoscreens IP2 Series Air Curtain
• NBS DescriptionAir curtain
• NBS Noten/a
• NBS Object NameThermoscreens - Air curtain
• NBS Office Master Tagn/a
• NBS Reference90-40-35/310
• Noise Output69 dB(A)
• Nominal Depth725.00 mm
• Nominal Height275.00 mm
• Nominal Length1500.00 mm
• Production Year2022
• Referenced Standardn/a
• Replacement Costn/a
• Return Offset Horizontal0.00 mm
• Return Offset Vertical0.00 mm
• Shapen/a
• Sizen/a
• Spare Partsn/a
• Supply Offset Horizontal0.00 mm
• Supply Offset Vertical0.00 mm
• TypeIP2_Nested : IP2-L-150
• Type CommentsThermoscreens IP2 Series Air Curtain
• Type NameIP2 L-1500-A-0 Simple RAL 9016
• URLthermoscreens.com/
• Vertical InstallationNo
• Warranty Descriptionn/a
• Warranty Duration Labor0
• Warranty Duration Parts5
• Warranty Duration UnitYear
• Warranty Guarantor Laborsales@thermoscreens.com
• Warranty Guarantor Partssales@thermoscreens.com
• Water Flow0 l/h
• Weight190.00 kg
