Alpha Flow Precast Concrete Permeable Paving Blocks
Description
Alpha Flow is a popular paving due to its rustic, distinguished appearance with tumbled edges, replicating traditional natural cobbles and setts. Not only is it aesthetically intriguing but it offers an environmentally friendly, permeable solution due to its special nib design. The nib design allows surface water to drain between the blocks, and into a specially designed substrate, making Alpha Flow the solution for the mitigation of surface water flooding ensuring there’s no ponding on the surface of the paving during and after a storm event.
With aesthetics and functionality combined, Alpha Flow provides a prestigious finish to the commercial environment, assisting in creating charming roads and sidewalks for new housing estates, parks, and city squares.
Read moreObject Data
1 Revision
Last Updated
18/05/2022
Available Software
BS1192:4
Compliant
BSB
Compliant
EPD
Available
Sustainability & Environmental Data
Approved Sustainability Data from an EPD
This data is supplied by the manufacturer and certified by an approved third party.
- Biogenic CO2e (A1-A3,B1-B5,C1-C4) 6.76 kg
- Total CO2e (Fossil) 13.9 kg
- Manufacturing (A1-A3) 13.9 kg
- Transport to Site (A4) 6.22 kg
- On-Site Installation (A5) 0 kg
- Use & Maintenance (B1-B5) kg
- End of Life (C1,C3,C4) 0.557 kg
- Recycled Content 0.1 %
- Recyclable Content 90 %
- Re-use Potential %
- Energy Recovery Possibility %
- Water Use 36.1 L
- Ozone Depletion Potential 8.15E‐7 mg CFC-11eq
- Expiry18th Nov 2022 - 18th Nov 2027
Environmental Product Declarations
Environmental Product Declaration (EPD)
Valid until 18th Nov 2027
