AP1 Canopy

by Chiltern Glass Fibre Limited

Download Add to collection

Description

The AP1 Canopies are an alternative option to traditional build and come with internal framework ready to take tiles.

This download contains Revit components for the Chiltern Glass Fibre Limited AP1 Canopy

Component includes 1no standard size;

- 2060 x 1300mm (50 Degree)

Object Data

1 Revision

Last Updated

18/04/2017

Available Software

BS1192:4

Compliant

BSB

Compliant

EPD

Not Available

Accompanying literature

Product Data Sheet

Object metadata

_Authorsales@chilternglassfibre.com
_Authorized ByKris Atkinson
_Bim Spec Guid0
_Bimstore Bible Version13
_Created Bywww.chilternglassfibre.com/
_Current Revision1
_Distributed Bywww.bimstore.co.uk
Accessibility Performancen/a
Analytic Construction<None>
Apex Height1300 mm
Apex Offset156 mm
Assembly CodeB2020
Asset TypeFixed
Base MaterialWhite
BIM Object NameAP1 - 2060 x 1300 50 Deg
Bracket Number2
Classification NameUniclass2015
Classification ValuePr_25_93_52_34
Code Performancen/a
ColorDark Grey
Constituentsn/a
Created Bysales@chilternglassfibre.com
Created OnMar2016
DescriptionAP1 Canopy
Documentation Certificatesn/a
Documentation Installation Guiden/a
Documentation Literaturen/a
Documentation Maintenancen/a
Documentation Technicaln/a
Duration UnitYears
Eaves Height120 mm
Eaves Offset30 mm
Expected Life0
Facia Start Offset147 mm
Fascia Depth130 mm
Fascia Thickness5 mm
Fax No.01246 251684
Featuresn/a
FinishPainted GRC
Floor Offset1800 mm
Gable Offset140 mm
Graden/a
Ifc Export AsWindow
Ifc Export Type IfcWindow
KeynoteH40
Length2060 mm
ManufacturerChiltern Glass Fibre
MaterialGRC
ModelAP1
Model NumberAP1 - 2060 x 1300 50 Deg
Model ReferenceAP1
NBS DescriptionGlass fibre reinforced concrete (GRC) door canopies
NBS Noten/a
NBS Object NameChilternGlassFibre-Glass fibre reinforced concrete (GRC) door canopies
NBS Office Master Tagn/a
NBS Reference45-75-30/365
Nominal Depth600 mm
Nominal Height1300 mm
Nominal Length2060 mm
Phone 101246 251679
Phone 201246 866624
Production Year2016
Projection600 mm
Rafter Depth100 mm
Rafter MaterialRafter
Rafter Thickness35 mm
Referenced Standardn/a
Replacement Cost0.0
Roof Pitch50.00 °
ShapeSquare
Size2060 x 1300
Spare Partsn/a
Type CommentsAP1 - 2060 x 1300 50 Deg
Type NameAP1 - 2060 x 1300 50 Deg
URLwww.chilternglassfibre.com
Warranty DescriptionWe offer a 2 Year Guarantee on all our products for faulty materials or workmanship
Warranty Duration Labor2
Warranty Duration Parts2
Warranty Duration UnitYears
Warranty Guarantor Laborsales@chilternglassfibre.com
Warranty Guarantor Partssales@chilternglassfibre.com

Sustainability & Environmental Data

Not available.

Environmental Product Declarations

There are no EPDs.
