Aztec Water Heaters

by Trianco

Download Add to collection

Description

Our Aztec Instant Hot Water Heater are a simple solution when hot water is required but only a cold water supply and electricity is available.

Our small compact units with touch screen control combine ‘State-of-the-art’ looks with performance available in 8kW and 12kW versions. Endless constant hot water has never been easier to obtain.

Unapproved

This content has not yet been through the Bimstore QA process and as such may not meet our minimum standards for content hosting.

Object Data

1 Revision

Last Updated

11/05/2020

Available Software

BS1192:4

Compliant

BSB

Compliant

EPD

Not Available

Accompanying literature

Installation Guide

Product Literature

Product Data Sheet

Object metadata

_AuthorIH
_Authorized Bybimstore
_Bim Spec Guid0
_BS Bible Version16
_Created Bywww.bimstore.co/
_Current Revision1
_Distributed Bywww.bimstore.co/
_Object User Guidewww.bimstore.co/
Access Clearance Bottom1400 mm
Access Clearance Front500 mm
Access Clearance Left0 mm
Access Clearance Rear0 mm
Access Clearance Right0 mm
Access Clearance Top0 mm
Accessibility Performancen/a
Asset TypeFixed
BIM Object NameTrianco_ElectricalFixture_Boiler_AztecWaterHeaters
BlackAztec Instant Water Heater - Screen
Bracket Depth3 mm
Classification NameUniclass2015
Classification ValuePr_60_60_08_27
Clearance MaterialClearance Zone
Code Performancen/a
ColorWhite
Constituentsn/a
Created Byinfo@trianco.co.uk
Created On2020-05-06T09:00:00
DescriptionOur small compact units with touch screen control combine ‘State-of-the-art’ looks with performance available in 8kW and 12kW versions. Endless constant hot water has never been easier to obtain.
Documentation Certificatestrianco.co.uk/aztec-instant-water-heater
Documentation Installation Guidewww.bimstore.co/products/aztec-water-heaters/document/installation-guide
Documentation Literaturewww.bimstore.co/products/aztec-water-heaters/document/product-literature
Documentation Maintenancetrianco.co.uk/aztec-instant-water-heater
Documentation Technicaltrianco.co.uk/aztec-instant-water-heater
Duration UnitYears
Expected Life0
Featuresn/a
FinishPaint - Glossy
Frequency50.00 Hz
Full Load Current51 A
Fuse Rating63 Amps
Graden/a
Gross Weight0.00 kg
Ifc Export AsIfcBoiler
Ifc Export TypeIfcBoilerTypeEnum.ELECTRIC
IK Ratingn/a
IP RatingIPX4D
k W12
ManufacturerTrianco
Manufacturer NameTrianco
MaterialStainless Steel
Maximum Operating Pressuren/a
Maximum Power Consumption12 kW
Minimum Operating Pressuren/a
Minimum Power Consumption12 kW
ModelAztec Instant Water Heater
Model Number12 kKW
Model ReferenceAztec Instant Water Heater
NBS DescriptionElectric boilers
NBS Object NameTrianco - Electric boilers
NBS Office Master Tagn/a
NBS Reference90-40-05/430
Nominal Depth51 mm
Nominal Height395 mm
Nominal Length255 mm
Production Year2020
Referenced Standardn/a
Replacement Costn/a
ShapeRectangle
Sizen/a
Spare Partsn/a
Starting Current12 kW
Supply Phase1
Type Comments12 kKW
Type Name12 kKW
Unit Depth48 mm
Unit Height395 mm
Unit Length255 mm
URLtrianco.co.uk/
Voltage230V
Warranty Description1 year from install back to base
Warranty Duration Labor1
Warranty Duration Parts1
Warranty Duration UnitYears
Warranty Guarantor Laborinfo@trianco.co.uk
Warranty Guarantor Partsinfo@trianco.co.uk
Water Content0
WhiteAztec Instant Water Heater - White
