Column Electric Radiator

by Stelrad Radiators Ltd

Download Add to collection

Description

The Column Electric radiator is a timeless design made from steel; its rounded, vertical tubes blend into any room and any décor with ease. Every model comes with a magnetic thermostat which can be attached to the radiator or removed and used separately.

The columns are filled with a fluid which is heated up using an electrical element immersed in the fluid inside. This maintenance free and specially formulated fluid is designed to distribute the heat quickly and evenly across the radiator, which in turn emits the heat into your room through radiation.

Click here to view our interactive brochure

Object Data

1 Revision

Last Updated

23/02/2024

Available Software

BS1192:4

Compliant

BSB

Compliant

EPD

Not Available

_AuthorAM
_Authorized Bybimstore
_Bim Spec Guid0
_BS Bible Version17
_Created Bywww.bimstore.co
_Current Revision1
_Distributed Bywww.bimstore.co
Accessibility Performancen/a
Anchor Offset Left101.06 mm
Array20
Assembly CodeD3020
Asset TypeFixed
BIM Object NameStelrad_MechanicalEquipment_Radiator_ColumnElectric
Btu/hr5121
Classification NameUniclass2015
Classification ValuePr_70_60_36_26
Class Of ProtectionII
Code Performancen/a
ColorAnthracite
Constituentsn/a
ControlsRemoveable Control
Created Byinfo@stelrad.com
Created On2024-01-11 T09:00:00
Default Elevation0.00 mm
DescriptionThe Column Electric radiator is a timeless design made from steel; its rounded, vertical tubes blend into any room and any décor with ease. Every model comes with a magnetic thermostat which can be attached to the radiator or removed and used separately. The columns are filled with a fluid which is heated up using an electrical element immersed in the fluid inside. This maintenance free and specially formulated fluid is designed to distribute the heat quickly and evenly across the radiator, which in turn emits the heat into your room through radiation.
Documentation Certificateswww.bimstore.co/products/column-electric/document/product-certificates
Documentation Installation Guidewww.bimstore.co/products/column-electric/document/installation-guide
Documentation Literaturewww.bimstore.co/products/column-electric/document/product-literature
Documentation Maintenancewww.bimstore.co/products/column-electric/document/maintenance-information
Documentation Technicalwww.bimstore.co/products/column-electric/document/technical-data-sheet
Duration UnitYear
Expected Life0
Featuresn/a
Finishn/a
First Section Offset55.06 mm
Graden/a
Heat Output1500 W
Heat SourceOil filled
Ifc Export AsIfcSpaceHeater
Ifc Export TypeIfcSpaceHeaterTypeEnum.RADIATOR
Indice Of ProtectionIP34
KeynoteT
Last Section Offset90.94 mm
ManufacturerStelrad
Manufacturer NameStelrad
Materialn/a
ModelColumn Electric
Model NumberColumn Electric
Model Reference600mm(H) x 1020mm(L) - Anthracite
NBS DescriptionElectric heated towel rails
NBS Noten/a
NBS Object NameStelrad - Electric heated towel rails
NBS Office Master Tagn/a
NBS Reference90-40-35/385
Nominal Depth66.00 mm
Nominal Height600.00 mm
Nominal Length1020.00 mm
Production Year2024
Radiator FinishStelrad - Metal - Anthracite
Referenced Standardn/a
Replacement Costn/a
Sizen/a
Spare Partsn/a
Type Comments600mm(H) x 1020mm(L) - Anthracite
Type Name600mm(H) x 1020mm(L) - Anthracite
UINE002-0600-1020
URLwww.stelrad.com
Voltage230 V ~ 50 Hz
Warranty Descriptionn/a
Warranty Duration Labor0
Warranty Duration Parts0
Warranty Duration UnitYear
Warranty Guarantor Laborn/a
Warranty Guarantor Partsinfo@stelrad.com
Weight30.40 kg
