Concealed Urinal Bowl

by Trade Washrooms

Download Add to collection

Description

Conceal pipework and wastes with this concealed urinal bowl for a cleaner washroom look. Part of our commercial sanitary ware range, this concealed urinal is perfect for public and office washrooms.

Object Data

1 Revision

Last Updated

02/01/2020

Available Software

BS1192:4

Compliant

BSB

Compliant

EPD

Not Available

Accompanying literature

Object User Guide

Technical Data Sheet

Product Data Sheet

Object metadata

_AuthorIan Holmes
_Authorized Bybimstore
_Bim Spec Guid0
_BS Bible Version16
_Created Bywww.bimstore.co
_Current Revision1
_Distributed Bywww.bimstore.co
Accessibility Performancen/a
Assembly CodeD2010
Asset TypeFixed
BIM Object NameTradeWashrooms_PlumbingFixture_Urinal_ConcealedBowl
CategoryPr_40_20_93_82:Wall-hung urinals
Classification NameUniclass2015
Classification ValuePr_40_20_93_82
Code PerformanceBS 5520
ColorWhite
ConstituentsUrinal bowl
Created Byspec@tradewashrooms.co.uk
Created On2019-06-14T09:00:00
CW ConnectionNo
CWFU0
DescriptionConcealed urinal bowl
Documentation Certificateswww.tradewashrooms.co.uk/urinals/urinal-bowls/concealed-urinal-bowl/
Documentation Installation Guidewww.tradewashrooms.co.uk/urinals/urinal-bowls/concealed-urinal-bowl/
Documentation Literaturewww.tradewashrooms.co.uk/urinals/urinal-bowls/concealed-urinal-bowl/
Documentation Maintenancewww.tradewashrooms.co.uk/urinals/urinal-bowls/concealed-urinal-bowl/
Documentation Technicalwww.tradewashrooms.co.uk/urinals/urinal-bowls/concealed-urinal-bowl/
Duration UnitYears
Expected Life25
FeaturesConcealed inlet and concealed waste
FinishVitreous China
GradeBS 3402
HW ConnectionNo
HWFU0
Ifc Export AsIfcFlowTerminalType
Ifc Export TypeIfcSanitaryTerminalTypeEnum.URINAL
KeynoteN13
Manufacturerspec@tradewashrooms.co.uk
Manufacturer Namespec@tradewashrooms.co.uk
MaterialCeramic
ModelConcealed Urinal Bowl
Model NumberURBOW
Model ReferenceConcealed Urinal Bowl
NameConcealed Urinal Bowl
NBS DescriptionWall-hung urinals
NBS Object NameTrade Washrooms - Wall-hung urinals
NBS Office Master Tagn/a
NBS Reference45-35-70/350
Nominal Depth315 mm
Nominal Height665 mm
Nominal Length410 mm
Primary MaterialCeramic, White
Production Year2019
Referenced StandardBS 3402, EN 13407
Replacement Costn/a
Shapen/a
Size315 x 410 x 665mm
Spare Partsn/a
Sustainability PerformanceEN 13407
Type CommentsURBOW
Type NameConcealed Urinal Bowl
URLwww.tradewashrooms.co.uk/
Vent ConnectionNo
Warranty Description25-year warranty on any manufacturing defect
Warranty Duration Labor0
Warranty Duration Parts25
Warranty Duration UnitYears
Warranty Guarantor Laborn/a
Warranty Guarantor Partsorders@tradewashrooms.co.uk
Waste ConnectionYes
WFU0
