D-POT

Object metadata

• _AuthorCH
• _Authorized ByVexo Int
• _Bim Spec Guid0
• _BS Bible Version16
• _Created ByVexo Int
• _Current Revision1
• _Distributed ByVexo Int
• A250 mm
• Accessibility Performancen/a
• ApplicationStainless Steel Dosing Pot
• Assembly CodeD20
• AssetIdentifier (default)Please record on commissioning
• Asset TypeFixed
• B115 mm
• BarCode (default)Please record on commissioning
• BIM Object NameVexo_PipeAccessories_D-Pot11L
• Body Finish250 mm
• Body Start0 mm
• Bracket Depth120 mm
• Bracket Offset R/L125 mm
• Bracket OIffset225 mm
• Bracket Rear Offset115 mm
• C210 mm
• Classification NameUniclass2015
• Classification ValuePr_75_51_17_78
• Code Performancen/a
• ColorGrey & Green
• Constituentsn/a
• Created ByCain Harbut
• Created Onwww.vexoint.com/
• Default Elevation1200 mm
• DescriptionD-Pot Stainless Steel Dosing Pot
• Documentation Certificateswww.vexoint.com/
• Documentation Installation Guidewww.vexoint.com/
• Documentation Maintenancewww.vexoint.com/
• Documentation Technicalwww.bimstore.co/products/d-pot-1/document/technical-data-sheet
• Dome Height68 mm
• Dosing Capacity11L
• Drain Cock Position85 mm
• Duration Unitn/a
• E68 mm
• Expected Lifen/a
• Featuresn/a
• Filter Body MountingWall or Floor Standing (Unistrut)
• FinishStainless Steel
• FittingsStainless Steel
• General DescriptionThe VEXO D-POT provides a quality, durable and cost effective stainless steel vessel with innovative fatigue resistant curved design which can be installed in a left or right handed configuration and is fully compliant with the latest BSRIA BG50/2013 recommendations to avoid dead-legs.
• Graden/a
• IFC Export AsN/A
• IFC Export TypeN/A
• Installation InformationD-POTs are designed to be installed internally within a building and to avoid risk of freezing and component damage. If installing externally the D-POT should be mounted within a weatherproof enclosure and insulated to avoid freezing otherwise the warranty will be voided
• InstallationDate (default)Please record on commissioning
• Isolation Valve Connections1/2” BSP Female
• Isolation ValvesStainless Steel
• Keynote​S                                  ​                                ​         ​                                         ​
• ManufacturerVexo Int
• Manufacturer NameVexo Int
• MaterialStainless Steel
• Max Working Pressure10Bar
• Max Working Temperature120oC
• ModelD-Pot Stainless Steel Dosing Pot
• Model NumberD-Pot Stainless Steel Dosing Pot
• Model ReferenceVDP-11L
• NBS DescriptionStainless Steel Dosing Pot
• NBS Object NameVexo Products - Stainless Steel Dosing Unit
• NBS Office Master TagN/A
• NBS ReferenceN/A
• Nominal Depth292 mm
• Nominal Height877 mm
• Nominal Length250 mm
• Nominal Width250 mm
• Non Return ValveStainless Steel
• Offset25 mm
• Offset Left120 mm
• Offset Right120 mm
• Product CodeVDP-11
• Production Year2020
• Referenced Standardn/a
• SerialNumber (default)Please record on commissioning
• ShapeCylindrical
• SizeN/A
• Tundish Height275 mm
• Type CommentsVDP-11L
• Type NameVDP-11L
• URLwww.vexoint.com/
• Vessel BodyStainless Steel
• Warranty Description5 Years Standard (6 Years if VEXOTM X-PO10 Inhibitor is used)
• Warranty Duration Laborn/a
• Warranty Duration Parts5 Years Standard (6 Years if VEXOTM X-PO10 Inhibitor is used)
• Warranty Duration Unit5 (6 Years if VEXOTM X-PO10 Inhibitor is used)
• Warranty Guarantor Partsn/a
• WarrantyStartDate (default)Please record on commissioning
• Weight (Full)20kg
• X-PO10 Inhibitor 10LVX-XPO10-10LTR
• X-PO20 De-Scaler 10LVX-XPO20-10LTR
• X-PO35 Non-Flush Cleanser 10LVX-XPO35-10LTR
• X-PO40 De-Sludger 10LVX-XPO40-10LTR
• X-PO45 New System 10LVX-XPO45-10LTR
• X-PO50 Anti-Freeze 20LVX-XPO50-20LTR
• X-PO55 Anti-Freeze 20LVX-XPO55-20LTR
• X-PO80 Biocide 5LVX-XPO80-5LTR
