Decor 560 Totalis Blackout System

Object metadata

• _authorRyan Wigham
• _created bywww.bimstore.co.uk
• _current revision1
• Assembly CodeE2010310
• Barcode0
• Colour Matched Hardwaredecor 560 hardware can be powdercoated to any standard RAL or BS colour to provide a match to aluminium curtain walling sections or other building components
• ContactDecor Systems, New Street, Doncaster, DN1 3QU - Tel: 03030 300 120 - Email: sales@decorsystems.co.uk
• Default Elevation1219 mm
• Descriptiondecor 550 Blackout Blinds are the perfect solution for total light control in laboratories, lecture theatres, conference rooms and teaching areas, being compact enough for small windows and door vision panels. A neat cassette headbox and matching interlocking aluminium side channels complete the decor 550 blackout blind.
• Fabrics Availabledecor Tempest, decor Dynasty, decor Mystique
• Fabrics Rangewww.decorsystems.co.uk/pages/blind_fabrics.html
• KeynoteN10/240
• ManufacturerDecor Systems
• Maximum Drop4000mm (4000mm - Manual Crank Operation) (4000mm - Electric Operation)
• Maximum Fabric Area4.8m² (4.8m² - Manual Crank Operation) (6.0m² - Electric Operation)
• Maximum Width2400mm (3000mm - Manual Crank Operation) (3000mm - Electric Operation)
• Minimum Drop400mm (400mm - Manual Crank Operation) (400mm - Electric Operation)
• Minimum Width500mm (500mm - Manual Crank Operation) (500mm - Electric Operation)
• ModelDecor 560 Totalis - Top Fix
• Serial Number0
• Solar Anodized SilverDecor Systems - Aluminum, Anodized Silver
• Solar BlackDecor Systems - Black
• Solar GreyDecor Systems - Grey
• Solar WhiteDecor Systems - White
• Tag Number0
• Type CommentsFully channelled blackout blind, heavy duty system for public use areas
• URLdecorsystems.co.uk/pages/products.html
• Webwww.decorsystems.co.uk
