Decor 590 Atria Blackout System

5.7k
0
- / 5
Rate this product

-

Compliant

BS1192:4

Compliant

BSB

Compliant

Object Data

1 Revision

Last Updated

13/03/2014

Download BIM

Add to collection

Available for:

decor 590 blackout blinds are designed for any non-vertical blackout application. Thanks to the constant tension system, the blind can be installed at any angle, horizontally, or even drawing up from bottom to top. The system has an alumnium cassette at each end, one to contain the roller and fabric and the other to contain the tensioning roller and cables.

The fabric is retained in the side guides vy the deco Edgefast system, making it suitable for use on opening windows.

This download contains a face fixed version of the Decor 590 Atria Blackout System.

_authorRyan Wigham
_created bywww.bimstore.co.uk
_current revision1
110mm CassetteYes
150mm CassetteNo
200mm CassetteNo
65mm CassetteNo
85mm CassetteNo
Assembly CodeE2010310
Barcode0
ContactDecor Systems, New Street, Doncaster, DN1 3QU - Tel: 03030 300 120 - Email: sales@decorsystems.co.uk
Default Elevation1219 mm
Descriptiondecor 590 blackout blinds are designed for any non-vertical blackout applications. Thanks to the constant tension system, the blind can be installed at any angle, horizontally, or even drawing up from bottom to top.
Fabrics Availabledecor Tempest, decor Alfresco, decor Zenith
Fabrics Rangewww.decorsystems.co.uk/pages/blind_fabrics.html
KeynoteN10/240
ManufacturerDecor Systems
Maximum Drop3200mm
Maximum Fabric Area5m²
Maximum Width3000mm
Minimum Drop500mm
Minimum Width700mm
ModelDecor 590 rooflight blackout blind system - 110mm Headbox
Serial Number0
Solar Anodized SilverDecor Systems - Aluminum, Anodized Silver
Solar BlackDecor Systems - Black
Solar GreyDecor Systems - Grey
Solar WhiteDecor Systems - White
Tag Number0
Type CommentsTensioned rooflight system for room darkening
URLdecorsystems.co.uk/pages/products.html
Webwww.decorsystems.co.uk
