Fig568 Anti-Vacuum valves are used to protect drying cylinders, storage cylinders, calorifiers and tankers from collapse due to internal vacuum. They are also used on the steam systems, to assist condensate drainage and to prevent suction of contents from vats. Vacuum Valves are normally fitted vertically, at the top of the vessel or pipeline being protected, horizontal revolving cylinders however should have a Fig 568 fitted at each end, diametrically opposite one another. The operation of valves in service should be checked every twelve months.

PTFE to metal seating
Gunmetal

_AuthorIH
_Authorized Bybimstore
_Bim Spec Guid0
_BS Bible Version16
_Created Bywww.bimstore.co
_Current Revision1
_Distributed Bywww.bimstore.co
_Object User Guidewww.bimstore.co/products/fig-568-anti-vacuum-valve/document/object-user-guide
A58 mm
A16 mm
A27 mm
A31 mm
A45 mm
A57 mm
A63 mm
A713 mm
Accessibility Performancen/a
Assembly CodeD2040100
Asset TypeFixed
B35 mm
B18 mm
B217 mm
B319 mm
B421 mm
B528 mm
B617 mm
B722 mm
BIM Object NameNABIC_PipeAccessories_Valves_AntiVacuum_Fig568
Classification NameUniclass2015
Classification ValuePr_65_54_95_42
Code Performancen/a
ColorGold
Connection Size15 mm
Constituentsn/a
Created Bynabicsales@cranebsu.com
Created On2020-08-05T09:00:00
DescriptionThe NABIC Fig 568 gunmetal Anti-Vacuum Valve is set to open at a vacuum pressure of 50mbar. A dust cap prevents entry of foreign matter. WRAS approved.
Documentation Certificateswww.bimstore.co/products/fig-568-anti-vacuum-valve/document/product-certificates
Documentation Installation Guidewww.bimstore.co/products/fig-568-anti-vacuum-valve/document/installation-guide
Documentation Literaturewww.bimstore.co/products/fig-568-anti-vacuum-valve/document/product-literature
Documentation Maintenancewww.bimstore.co/products/fig-568-anti-vacuum-valve/document/maintenance-information
Documentation Technicalwww.bimstore.co/products/fig-568-anti-vacuum-valve/document/technical-data-sheet
Duration UnitYears
End ConnectionsBSPT (R) BS EN 10226-2. Male connections, R1/2, R3/4”, R1”, R1 1/4”, R1 1/2” and R2” available.
Expected Life0
Featuresn/a
Finishn/a
Fitting MaterialBrass
Graden/a
Ifc Export AsIfcValve
Ifc Export TypeIfcValveTypeEnum.ANTIVACUUM
KeynoteS
ManufacturerNABIC
Manufacturer NameNABIC
MaterialBronze
MediumHot water, steam and air
ModelAnti-Vacuum Valve - Fig 568
Model NumberN-568-015
Model ReferenceAnti-Vacuum Valve - Fig 568
NBS DescriptionIn-line anti-vacuum backflow prevention devices
NBS Object NameNABIC - In-line anti-vacuum backflow prevention devices
NBS Office Master Tagn/a
NBS Reference90-10-90/442
Nominal Depth28 mm
Nominal Diameter15 mm
Nominal Height58 mm
Nominal Length28 mm
Pressure Rating13.5 bar
Production Year2020
Product Page URLwww.nabicvalves.com/product/anti-vacuum-valves/fig-568-antivacuum-valve
Product TestingAll valves are 100% production tested.
Referenced Standardn/a
Replacement Costn/a
Shapen/a
SizeDN15
Spare Partsn/a
Temperature Rating-20 Degree C to 195 Degree C
Type CommentsN-568-015
Type NameN-568-015
URLwww.nabicvalves.com/
Warranty Descriptionn/a
Warranty Duration Labor0
Warranty Duration Parts5
Warranty Duration UnitYears
