Flat Roof Smoke Ventilator - FRD S12 AOV

by Keylite Roof Windows

Download Add to collection

Description

Keylite Flat Roof Smoke Ventilator

The Keylite Flat Roof Smoke Ventilators (FRD-AOV) are electrically operated smoke vents designed to allow the release of smoke from buildings in the event of a fire.

All Keylite Flat Roof Smoke Ventilators and smoke controls are fully tested and compliant with EN 12101-2, EN 12101-9 and EN 12101-10.

- Wide range of sizes available to provide opening vents with Smoke Ventilation areas of 0.88m2, 1.0m2 & 1.5m2

- Opens to 160° within 60 seconds.

- Accessories include control panels, detectors and manual control points.

- Actuator can be offset for access purposes as well.

- 300mm PVC upstand.

Object Data

1 Revision

Last Updated

02/07/2021

Available Software

EPD

Not Available

Accompanying literature

Object User Guide

Product Data Sheet

Object metadata

_AuthorAM
_Authorized Bybimstore
_Bim Spec Guid0
_BS Bible Version16
_Created Bywww.bimstore.co
_Current Revision2
_Distributed Bywww.bimstore.co
Accessibility Performancen/a
Aerodynamic Area Aa0.80 m²
Assembly CodeD3090300
Asset TypeFixed
BIM Object NameKeylite_Rooflights_Smoke AndHeatVentilation_FRD-S12-AOV-DSP
Classification NameUniclass2015
Classification ValuePr_70_65_04_56
Code Performancen/a
Colorn/a
Constituentsn/a
Created ByKeylite
Created On19-05-2021 T09:00:00
Current3 A
Depth1200 mm
DescriptionRoof Single Leaf - Residential
Documentation Certificateswww.keyliteroofwindows.com
Documentation Installation Guidewww.keyliteroofwindows.com
Documentation Literaturewww.keyliteroofwindows.com/products/roof-windows/flat-roof-dome/flat-roof-smoke-ventilation/
Documentation Maintenancewww.keyliteroofwindows.com
Documentation Technicalwww.keyliteroofwindows.com
Duration UnitYear
Expected Life0
Featuresn/a
Finishn/a
Free Area1.34 m²
Geometric Area1.44 m²
Graden/a
G Value Clear0.75
G Value Diffused0.63
Ifc Export AsIfcDoorStyle
Ifc Export TypeUSERDEFINED
Insulated LidNo
KeynoteL20/810
ManufacturerKeylite
Manufacturer NameSERTUS
Materialn/a
Material DomePolycarbonate
Material FrameuPVC
ModelFRD S12 AOV DSP
Model NumberDouble Skin
Model ReferenceFRD S12 AOV DSP
Motor Offset200 mm
Motor Position CenterNo
NBS DescriptionNatural smoke and heat exhaust ventilators
NBS Object NameKeylite - Natural smoke and heat exhaust ventilators
NBS Office Master Tagn/a
NBS Reference90-45-80/340
Nominal Depth1200 mm
Nominal Height0 mm
Nominal Length1200 mm
Production Year2021
Referenced StandardFire Ratings to BS 476: Part 3: AA; To BS 476: Part 3: Class 1; To 1991 Building Regulations: Tp(a)
Replacement Costn/a
ShapeSquare
Size1200mm(W) x 1200mm(L)
Spare Partsn/a
Type CommentsDouble Skin
Type InstallationFRD AOV DSP
Type NameDouble Skin
URLwww.keyliteroofwindows.com/products/roof-windows/flat-roof-dome/flat-roof-smoke-ventilation/
U Value2.22
Voltage24 V
Warranty Descriptionn/a
Warranty Duration Labor0
Warranty Duration Parts3
Warranty Duration UnitYear
Warranty Guarantor Laborinfo@keyliteuk.com
Warranty Guarantor Partsinfo@keyliteuk.com
Weight63.00 kg
Width1200 mm
