Galvanised Steel Ties - Truss Clips TC38

Object metadata

• _AuthorAM
• _Authorized Bybimstore
• _Bim Spec Guid0
• _BS Bible Version16
• _Created Bywww.bimstore.co
• _Current Revision1
• _Distributed Bywww.bimstore.co
• _Object User Guidewww.bimstore.co/products/galvanised-steel-ties-truss-clips-tc38/document/object-user-guide
• Accessibility Performancen/a
• Assembly CodeB1020
• Asset TypeFixed
• BIM Object NameExpamet_GalvanizedSteelTies_TrussClips_TC38_2D
• Classification NameUniclass2015
• Classification ValuePr_20_29_14_90
• Code PerformanceBS EN 10346:2015, DX51D + Z275
• ColorSteel
• Constituentsn/a
• Created Byinfo@birtleygroup.co.uk
• Created On2019-06-18 T09:00:00
• Description38mm truss clip to attach girders and rafters to wall plates.
• Documentation Certificateswww.expamet.co.uk/
• Documentation Installation Guidewww.expamet.co.uk/
• Documentation Literaturewww.expamet.co.uk/
• Documentation Maintenancewww.expamet.co.uk/
• Documentation Technicalwww.expamet.co.uk/
• Duration UnitYears
• Expected Life0
• Features0.9mm Thick Hot Dip Galvanized
• FinishHot Dip Galvanized Mild Steel
• Graden/a
• Ifc Export AsIfcMember
• Ifc Export TypeIfcMemberTypeEnum.PLATE
• KeynoteG10/130
• ManufacturerExpamet
• Manufacturer NameExpamet
• MaterialHot Dip Galvanized Mild Steel
• ModelTC38
• Model Number38mm truss clip
• Model ReferenceTC38
• NBS DescriptionTruss clips
• NBS Object NameExpamet; Truss clips
• NBS Office Master Tagn/a
• NBS Reference45-50-50/435
• Nominal Depth0.90 mm
• Nominal Height117.50 mm
• Nominal Length114.30 mm
• Production Year2019
• Referenced StandardBS EN 10346:2015, DX51D + Z275
• Replacement Costn/a
• Shapen/a
• Size117.5mm x 114.3mm
• Spare Partsn/a
• Thickness0.90 mm
• Type Comments38mm truss clip
• Type NameTC38
• URLwww.expamet.co.uk/
• Warranty Descriptionn/a
• Warranty Duration Labor0
• Warranty Duration Parts0
• Warranty Duration UnitYears
• Warranty Guarantor Laborinfo@birtleygroup.co.uk
• Warranty Guarantor Partsinfo@birtleygroup.co.uk
