Grohe Bau Classic 210 - 26699000

Object metadata

• _AuthorJY
• _Authorized Bybimstore
• _Bim Spec Guid0
• _BS Bible Version16
• _Created Bywww.bimstore.co
• _Current Revision1
• _Distributed Bywww.bimstore.co
• _Object User Guiden/a
• Accessibility Performancen/a
• Assembly CodeD2010
• Asset TypeFixed
• BIM Object NameGrohe_PlumbingFixtures_BauClassic210_26699000
• Classification NameUniclass2015
• Classification ValuePr_40_20_87_75
• Code Performancen/a
• ColorSilver
• Constituentsn/a
• Created Byinfo-uk@grohe.com
• Created On2019-09-24T09:00:00
• Default Elevation1219 mm
• DescriptionBau System 210 Shower system with thermostat for wall mounting consisting of:horizontal swivable 390 mm shower arm exposed thermostat with Aquadimmer function allows change between: head shower Tempesta 100 spray plate white spray pattern: Rain with ball joint rotation angle ± 15° hand shower Tempesta 100 spray pattern: Rain adjustable in height with gliding element Rotaflex shower hose 1750 mm 1/2" x 1/2" (28 410) GROHE EcoJoy 9.5 l/min flow limiter GROHE TurboStat compact cartridge with wax thermoelement GROHE SafeStop safety button at 38°C GROHE SafeStop Plus integrated temperature limiter at max 50°C GROHE DreamSpray perfect spray pattern GROHE StarLight chrome finish SpeedClean anti-lime system Inner WaterGuide for a longer lifeTwistfree to prevent hose from twisting suitable for instantaneous heaters from 18 kW/h minimum flow rate 7 l/min min. recommended pressure 1.0 bar optional upgrade: GROHE EasyReach tray (26 362), sold separately
• Documentation Certificateswww.grohe.co.uk/en_gb/
• Documentation Installation Guidewww.grohe.co.uk/en_gb/
• Documentation Literaturewww.grohe.co.uk/en_gb/
• Documentation Maintenancewww.grohe.co.uk/en_gb/
• Documentation Technicalwww.grohe.co.uk/en_gb/
• Duration UnitYears
• Expected Life0
• FeaturesBau System 210 Shower system with thermostat for wall mounting consisting of:horizontal swivable 390 mm shower arm exposed thermostat with Aquadimmer function allows change between: head shower Tempesta 100 spray plate white spray pattern: Rain with ball joint rotation angle ± 15° hand shower Tempesta 100 spray pattern: Rain adjustable in height with gliding element Rotaflex shower hose 1750 mm 1/2" x 1/2" (28 410) GROHE EcoJoy 9.5 l/min flow limiter GROHE TurboStat compact cartridge with wax thermoelement GROHE SafeStop safety button at 38°C GROHE SafeStop Plus integrated temperature limiter at max 50°C GROHE DreamSpray perfect spray pattern GROHE StarLight chrome finish SpeedClean anti-lime system Inner WaterGuide for a longer lifeTwistfree to prevent hose from twisting suitable for instantaneous heaters from 18 kW/h minimum flow rate 7 l/min min. recommended pressure 1.0 bar optional upgrade: GROHE EasyReach tray (26 362), sold separately
• FinishChrome
• Graden/a
• Ifc Export AsIfcPipeFitting
• Ifc Export TypeIfcPipeFittingType
• KeynoteN13
• ManufacturerGrohe
• Manufacturer NameGrohe
• MaterialChrome
• ModelBauClassic 210 shower system THM 9,5l F
• Model Number26699000
• Model ReferenceBauClassic 210 shower system THM 9,5l F
• NBS DescriptionShower fittings package
• NBS Object NameGrohe - Shower fittings package
• NBS Office Master Tagn/a
• NBS Reference45-35-70/330
• Nominal Depth0 mm
• Nominal Height0 mm
• Nominal Length0 mm
• Production Year2019
• Referenced Standardn/a
• Replacement Costn/a
• Shapen/a
• Sizen/a
• Spare Partsn/a
• Type Comments26699000
• Type NameBauClassic 210 shower system THM 9,5l F
• URLwww.grohe.co.uk/en_gb/
• Warranty Descriptionn/a
• Warranty Duration Labor0
• Warranty Duration Parts0
• Warranty Duration UnitYears
• Warranty Guarantor Laborn/a
• Warranty Guarantor Partsinfo-uk@grohe.com
