Grohe Essence New - Single-Lever Basin Mixer - 23541001

by GROHE

Download Add to collection

Description

GROHE SilkMove® 28 mm ceramic cartridge with temperature limiter.

GROHE StarLight® chrome finish.

GROHE EcoJoy® mousseur 5.7 l/min.

GROHE AquaGuide adjustable mousseur.

GROHE QuickFix® Plus installation system

This download is a face based plumbing fixture component created by bimstore.co.uk for Grohe.

This component is created in Revit 2014 for use in MEP systems and is in line with 2015 industry standards.

Object Data

1 Revision

Last Updated

22/03/2016

Available Software

BS1192:4

Compliant

BSB

Compliant

EPD

Not Available

Accompanying literature

Technical Data Sheet

Product Data Sheet

Object metadata

_authorized byKris Atkinson
_BIMspec_GUID0
_created byRyan Lashley
_current revision1
_distributed bywww.bimstore.co.uk
ADA CompliantNo
Assembly CodeC1030220
Asset TypeFixed
Classification NameUniclass 2015
Classification ValuePr_40_20_87_96
Cold Water Connection Diameter10 mm
ColorChrome
Contact GroheGROHE Limited, World Business Centre 2, Newall Road, London Heathrow Airport, Hounslow, Middlesex, TW6 2SF - Tel: +44 (0) 871 200 3414 - Fax: +44 (0) 871 200 3415 - EMail: info-uk@grohe.com
Created Byinfo-uk@grohe.com
Created OnMarch 2016
CW ConnectionYes
CWFU4.5
Default Elevation600 mm
DescriptionEssence New. Single-lever basin mixer 1/2 L-Size. single hole installation. swivel spout with mousseur and stop limiter. smooth body. flexible connection hoses. metal lever. min. recommended pressure 1.0 bar
Documentation Maintenanced3unq1hljpybmw.cloudfront.net/tpi/1000/1900/1940/1948/1948997/original/1948997.pdf
Documentation Technicald3unq1hljpybmw.cloudfront.net/tpi/1000/1800/1880/1880/1880290/original/1880290.pdf
Duration UnitYears
EcojoyNo
Expected Life0
Faucet MaterialGrohe-Chrome
FeaturesGROHE SilkMove® 28 mm ceramic cartridge with temperature limiter. GROHE StarLight® chrome finish. GROHE EcoJoy® mousseur 5.7 l/min. GROHE AquaGuide adjustable mousseur. GROHE QuickFix® Plus installation system
FinishChrome
Height244 mm
Hot Water Connection Diameter10 mm
HW ConnectionYes
HWFU4.5
Industry Standardsn/a
KeynoteN13
Length144 mm
Low Emitting MaterialNo
ManufacturerGrohe Limited
Masterformat Number01 52 19
Masterformat TitleSanitary Facilities
MaterialChrome
ModelEssence New - Single-Lever Basin Mixer
Model NumberEssence New - 23541001
NBS DescriptionWater supply fittings for wash basins and troughs;
NBS Object NameWater supply fittings for wash basins and troughs;
NBS Reference45-35-70/371
Product Documentation Linkwww.grohe.com/30898/search/search-result/product-details/?product=23541-G412&color=001&material=23541001
Product Page URLwww.grohe.com/30898/search/search-result/product-details/?product=23541-G412&color=001&material=23541001
Production Year2016
Size100x144x244mm
Type CommentsEssence New - 23541001
Type NameEssence New - Single-Lever Basin Mixer
URLwww.grohe.com
Vent ConnectionNo
Warranty Duration UnitYears
Waste ConnectionNo
WFU0
Width100 mm
