Grohe Essence - Single-Lever Basin Mixer - 23589001

3.4k
0
- / 5
Rate this product

-

Compliant

BS1192:4

Compliant

BSB

Compliant

Object Data

1 Revision

Last Updated

19/07/2017

Download BIM

Add to collection

Available for:

Single hole installationMetal leverGROHE SilkMove 28 mm ceramic cartridge with temperature limiterGROHE StarLight chrome finishGROHE EcoJoy mousseur 5.7 l/minGROHE AquaGuide adjustable mousseurGROHE QuickFix Plus installation systempop-up waste set 1 1/4"flexible connection hoses

This download is a face based plumbing fixture component created by bimstore.co.uk for Grohe.

This component is created in Revit 2015 for use in MEP systems and is in line with 2015 industry standards.

_AuthorRW
_Authorized ByKris Atkinson
_Bim Spec Guid0
_BS Bible Version14
_Created Bywww.bimstore.co.uk
_Current Revision1
_Distributed Bywww.bimstore.co.uk
Accessibility Performancen/a
ADA CompliantNo
Assembly CodeD2010
Asset TypeFixed
BIM Object NamePlumbingFixture_GroheLimited_Essence_SingleLeverMixer_23589001_METRIC
Classification NameUniclass2015
Classification ValuePr_40_20_87_98
Code Performancen/a
Cold Water Connection Diameter10 mm
ColorChrome
Constituentsn/a
Created Byinfo-uk@grohe.com
Created On2017-06-01T09:00:00
CW ConnectionYes
CWFU4.5
Default Elevation0 mm
DescriptionSingle hole installation metal lever GROHE SilkMove 28 mm ceramic cartridge with temperature limiter GROHE StarLight chrome finish GROHE EcoJoy mousseur 5.7 l/min GROHE AquaGuide adjustable mousseur GROHE QuickFix Plus installation system pop-up waste set 1 1/4'' flexible connection hoses
Documentation Certificatesn/a
Documentation Installation Guiden/a
Documentation Literaturen/a
Documentation Maintenancen/a
Documentation Technicaln/a
Duration UnitYears
EcojoyYes
Expected Life0
FeaturesSingle hole installation metal lever GROHE SilkMove 28 mm ceramic cartridge with temperature limiter GROHE StarLight chrome finish GROHE EcoJoy mousseur 5.7 l/min GROHE AquaGuide adjustable mousseur GROHE QuickFix Plus installation system pop-up waste set 1 1/4'' flexible connection hoses
FinishChrome
Graden/a
Hot Water Connection Diameter10 mm
HW ConnectionYes
HWFU4.5
Ifc Export AsIfcPipeFitting
Ifc Export TypeIfcPipeFittingType
Industry Standardsn/a
KeynoteN13
LEED Creditn/a
Low Emitting MaterialNo
ManufacturerGrohe Limited
Manufacturer NameGrohe Limited
Masterformat Number01 52 19
Masterformat TitleSanitary Facilities
MaterialChrome
ModelEssence Single-lever basin mixer 1/2'' S-Size
Model Number23589001
Model ReferenceEssence Single-lever basin mixer 1/2'' S-Size
NBS DescriptionWashbasin taps
NBS Object NameGrohe Limited - Water supply fittings for wash basins and troughs
NBS Office Master Tagn/a
NBS Reference45-35-70/371
Nominal Depth116 mm
Nominal Height208 mm
Nominal Length34 mm
Percentage Of Recycled Contentn/a
Pipe MaterialGroheLimited-Pipework
Primary MaterialGroheLimited-Chrome
Product Documentation Linkcdn.cloud.grohe.com/tpi/1000/1900/1920/1920/1920351/original/1920351.pdf
Production Year2017
Product Page URLwww.grohe.co.uk/en_gb/essence-basin-mixer-1-2-s-size-23589001.html
Referenced Standardn/a
Replacement Costn/a
Shapen/a
Sizen/a
Spare Partsn/a
Type Comments23589001
Type NameEssence Single-lever basin mixer 1/2'' S-Size
URLwww.grohe.com
Vent ConnectionNo
Warranty Descriptionn/a
Warranty Duration Laborn/a
Warranty Duration Partsn/a
Warranty Duration UnitYears
Warranty Guarantor Laborinfo-uk@grohe.com
Warranty Guarantor Partsinfo-uk@grohe.com
Waste ConnectionNo
WFU0
