Grohe Grohtherm 1000 Cosmopolitan M - Thermostatic Bath Mixer - 34441002

by GROHE

Download Add to collection

Description

GROHE StarLight® chrome finish.

GROHE TurboStat® C3 compact cartridge with wax thermoelement.

GROHE MetalGrip ergonomically shaped metal handles.

GROHE SafeStop at 38°C.

GROHE SafeStop Plus integrated temperature limiter at max 50°C.

GROHE EcoJoy® technology for less water and perfect flow automatic diverter: bath/shower.

This download is a face based plumbing fixture component created by bimstore.co.uk for Grohe.

This component is created in Revit 2014 for use in MEP systems and is in line with 2015 industry standards.

Object Data

1 Revision

Last Updated

22/03/2016

Available Software

BS1192:4

Compliant

BSB

Compliant

EPD

Not Available

Accompanying literature

Product Data Sheet

Object metadata

_authorized byKris Atkinson
_BIMspec_GUID0
_created byRyan Lashley
_current revision1
_distributed bywww.bimstore.co.uk
ADA CompliantNo
Assembly CodeC1030220
Asset TypeFixed
Classification NameUniclass 2015
Classification ValuePr_40_20_87_07
Cold Water Connection Diameter10 mm
ColorChrome
Contact GroheGROHE Limited, World Business Centre 2, Newall Road, London Heathrow Airport, Hounslow, Middlesex, TW6 2SF - Tel: +44 (0) 871 200 3414 - Fax: +44 (0) 871 200 3415 - EMail: info-uk@grohe.com
Created Byinfo-uk@grohe.com
Created OnMarch 2016
CW ConnectionYes
CWFU4.5
Default Elevation600 mm
DescriptionGrohtherm 1000 Cosmopolitan M. Thermostatic bath mixer 1/2. wall mounted. volume handle with GROHE EcoButton (economy button with individually adjustable economy stop). integrated mixed water shut off. ceramic headpart 1/2, 180°. shower bottom outlet 1/2. mousseur. built-in non return valves. dirt strainers. S-unions. metal escutcheon. protected against backflow. min. recommended pressure 1.0 bar
Documentation Maintenancecdn08.grohe.com/lib/1/tpi/1948997.pdf
Documentation Technicalcdn08.grohe.com/lib/1/tpi/1918079.pdf
Duration UnitYears
EcojoyYes
Expected Life0
Faucet MaterialGrohe-Chrome
FeaturesGROHE StarLight® chrome finish. GROHE TurboStat® C3 compact cartridge with wax thermoelement. GROHE MetalGrip ergonomically shaped metal handles. GROHE SafeStop at 38°C. GROHE SafeStop Plus integrated temperature limiter at max 50°C. GROHE EcoJoy® technology for less water and perfect flow automatic diverter: bath/shower.
FinishChrome
Height70 mm
Hot Water Connection Diameter10 mm
HW ConnectionYes
HWFU4.5
Industry Standardsn/a
KeynoteN13
Length170 mm
Low Emitting MaterialNo
ManufacturerGrohe Limited
Masterformat Number01 52 19
Masterformat TitleSanitary Facilities
MaterialChrome
ModelGrotherm 1000 Cosmopolitan M - Thermostatic Bath Mixer
Model NumberGrotherm 1000 Cosmopolitan M - 34441002
NBS DescriptionWater supply fittings for baths;
NBS Object NameWater supply fittings for baths;
NBS Reference45-35-70/315
Product Documentation Linkwww.grohe.com/30898/search/search-result/product-details/?product=34441-G416&color=002&material=34441002
Product Page URLwww.grohe.com/30898/search/search-result/product-details/?product=34441-G416&color=002&material=34441002
Production Year2016
Size298x170x70mm
Type CommentsGrotherm 1000 Cosmopolitan M - 34441002
Type NameGrotherm 1000 Cosmopolitan M - Thermostatic Bath Mixer
URLwww.grohe.com
Vent ConnectionNo
Warranty Duration UnitYears
Waste ConnectionNo
WFU0
Width298 mm
