Grohe Rapido U - 37338000

by GROHE

Download Add to collection

Description

roughing-in set for urinalfor manual actuation or Tectroninfra-red electronic 6 V or 230 Vwith stop valveflow pressure min 0.5 baroperating pressure max 10 barflush aidfunctional unit checked ex factorywater supply connections ½" outer threadconnecting box for mains supplyinstallation box with gasketfixing points for dry cladding and masonry-ininspection shaft incl. protection

This download is a face based plumbing fixture component created by bimstore.co.uk for Grohe.

This component is created in Revit 2015 for use in MEP systems and is in line with 2015 industry standards.

Object Data

1 Revision

Last Updated

24/05/2017

Available Software

BS1192:4

Compliant

BSB

Compliant

EPD

Not Available

Accompanying literature

Product Data Sheet

Object metadata

_AuthorRyan Lashley
_Authorized ByKris Atkinson
_Bim Spec Guid0
_BS Bible Version14
_Created Bywww.bimstore.co.uk
_Current Revision1
_Distributed Bywww.bimstore.co.uk
Accessibility Performancen/a
ADA CompliantNo
Assembly CodeD2010
Asset TypeFixed
BIM Object NamePlumbingFixture_GroheLimited_RapidoU_37338000_METRIC
Classification NameUniclass2015
Classification ValuePr_40_20_93_79
Code Performancen/a
Cold Water Connection Diameter10 mm
ColorBlue
Constituentsn/a
Contact GroheGROHE Limited, World Business Centre 2, Newall Road, London Heathrow Airport, Hounslow, Middlesex, TW6 2SF - Tel: +44 (0) 871 200 3414 - Fax: +44 (0) 871 200 3415 - Email: info-uk@grohe.com
Created Byinfo-uk@grohe.com
Created On2017-05-08T00:00:00
CW ConnectionNo
CWFU4.5
Default Elevation0 mm
Descriptionroughing-in set for urinal. for manual actuation or Tectron. infra-red electronic 6 V or 230 V. with stop valve. flow pressure min 0.5 bar. operating pressure max 10 bar. flush aid. functional unit checked ex factory. water supply connections ½" outer thread. connecting box for mains supply. installation box with gasket. fixing points for dry cladding and masonry-in. inspection shaft incl. protection.
Documentation Certificatesn/a
Documentation Installation Guiden/a
Documentation Literaturen/a
Documentation Maintenancen/a
Documentation Technicaln/a
Duration UnitYears
EcojoyNo
Expected Life0
Featuresroughing-in set for urinal. for manual actuation or Tectron. infra-red electronic 6 V or 230 V. with stop valve. flow pressure min 0.5 bar. operating pressure max 10 bar. flush aid. functional unit checked ex factory. water supply connections ½" outer thread. connecting box for mains supply. installation box with gasket. fixing points for dry cladding and masonry-in. inspection shaft incl. protection.
FinishPlastic
Graden/a
Hot Water Connection Diameter10 mm
HW ConnectionNo
HWFU4.5
Ifc Export AsIfcPipeFitting
Ifc Export TypeIfcPipeFittingType
Industry Standardsn/a
KeynoteN13
LEED Creditn/a
Low Emitting MaterialNo
ManufacturerGrohe Limited
Manufacturer NameGrohe Limited
Masterformat Number01 52 19
Masterformat TitleSanitary Facilities
MaterialPlastic
ModelGROHE Rapido U
Model Number37338000
Model ReferenceGROHE Rapido U
NBS DescriptionUrinal flushing valves
NBS Object NameGrohe Limited - Urinal flushing valves
NBS Office Master Tagn/a
NBS Reference45-35-70/355
Nominal Depth0 mm
Nominal Height0 mm
Nominal Length0 mm
Percentage Of Recycled Contentn/a
Product Documentation Linkwww.grohe.co.uk/en_gb/rapido-u-grohe-rapido-u-37338000.html
Production Year2017
Product Page URLwww.grohe.co.uk/en_gb/rapido-u-grohe-rapido-u-37338000.html
Referenced Standardn/a
Replacement Costn/a
Shapen/a
Sizen/a
Spare Partsn/a
Type Comments37338000
Type NameGROHE Rapido U
URLwww.grohe.com
Vent ConnectionNo
Warranty Descriptionn/a
Warranty Duration Laborn/a
Warranty Duration Partsn/a
Warranty Duration UnitYears
Warranty Guarantor Laborinfo-uk@grohe.com
Warranty Guarantor Partsinfo-uk@grohe.com
Waste ConnectionNo
WFU0
