TEMPESTA COSMOPOLITAN SYSTEM 250 CUBE Shower system with bath thermostat for wall mounting (26691000)

by GROHE

Download Add to collection

Description

Shower system with bath thermostat for wall mounting consisting of:

horizontal swivable 390 mm shower arm
exposed thermostat with Aquadimmer function
allows change between:
head shower Tempesta 250 Cube
spray pattern: Rain including GROHE DripStop
with ball joint
rotation angle ± 10°
bath inlet
separate diverter for hand shower
Hand shower Tempesta Cosmopolitan 100 (27 571)
2 spray patterns: Rain, Jet
adjustable in height with gliding element
Rotaflex shower hose 1750 mm 1/2" x 1/2" (28 410)
GROHE TurboStat compact cartridge with wax thermoelement
GROHE SafeStop safety button at 38°C
GROHE SafeStop Plus optional temperature limiter at 43°C included
GROHE DreamSpray perfect spray pattern
GROHE StarLight chrome finish
GROHE DripStop no more after dripping (head shower)
SpeedClean anti-lime system
Inner WaterGuide for a longer life
Twistfree to prevent hose from twisting
suitable for instantaneous heaters from 18 kW/h
minimum flow rate 7 l/min
min. recommended pressure 1.0 bar

Object Data

1 Revision

Last Updated

06/11/2020

Available Software

BS1192:4

Compliant

BSB

Compliant

EPD

Not Available

Accompanying literature

Product Data Sheet

Object metadata

_AuthorRL
_Authorized Bybimstore
_Bim Spec Guid0
_BS Bible Version16
_Created Bywww.bimstore.co
_Current Revision1
_Distributed Bywww.bimstore.co
_Object User Guidewww.bimstore.co
Accessibility Performancen/a
ADA CompliantNo
Assembly CodeD2010710
Asset TypeFixed
BIM Object NameGrohe_PlumbingFixture_TempestaSystem250_Cube_ShowerSystem_26691000
Classification NameUniclass 2015
Classification ValuePr_40_20_87_76
Code Performancen/a
Cold Water Connection Diameter10 mm
Colorn/a
Constituentsn/a
Contact Groheinfo-uk@grohe.com
Created Byinfo-uk@grohe.com
Created On2020-06-01T09:00:00
CWFU4.5
Default Elevation0 mm
DescriptionShower system with bath thermostat for wall mounting. consisting of: horizontal swivable 390 mm shower arm. exposed thermostat with Aquadimmer function. allows change between: head shower Tempesta 250 Cube (26 685). spray pattern: Rain. head shower with white rear cover. with ball joint. rotation angle ± 10°. GROHE EcoJoy 9.5 l/min flow limiter. bath inlet. separate diverter for hand shower. Hand shower Tempesta Cosmopolitan 100 (27 571). 2 spray patterns: Rain, Jet. GROHE EcoJoy 5.7 l/min flow limiter. adjustable in height with gliding element. Rotaflex shower hose 1750 mm 1/2" x 1/2" (28 410). GROHE EcoJoy technology for less water and perfect flow. GROHE TurboStat compact cartridge with wax thermoelement. GROHE SafeStop safety button at 38°C. GROHE SafeStop Plus optional temperature limiter at 43°C included. GROHE DreamSpray perfect spray pattern. GROHE StarLight chrome finish. SpeedClean anti-lime system. Inner WaterGuide for a longer life. Twistfree to prevent hose from twisting. suitable for instantaneous heaters from 18 kW/h. minimum flow rate 7 l/min. min. recommended pressure 1.0 bar.
Documentation Certificateswww.bimstore.co
Documentation Installation Guidewww.bimstore.co
Documentation Literaturewww.bimstore.co
Documentation Maintenancewww.bimstore.co
Documentation Technicalwww.bimstore.co
Duration UnitYears
EcojoyYes
Expected Life0
Faucet MaterialGrohe-Chrome
FeaturesShower system with bath thermostat for wall mounting. consisting of: horizontal swivable 390 mm shower arm. exposed thermostat with Aquadimmer function. allows change between: head shower Tempesta 250 Cube (26 685). spray pattern: Rain. head shower with white rear cover. with ball joint. rotation angle ± 10°. GROHE EcoJoy 9.5 l/min flow limiter. bath inlet. separate diverter for hand shower. Hand shower Tempesta Cosmopolitan 100 (27 571). 2 spray patterns: Rain, Jet. GROHE EcoJoy 5.7 l/min flow limiter. adjustable in height with gliding element. Rotaflex shower hose 1750 mm 1/2" x 1/2" (28 410). GROHE EcoJoy technology for less water and perfect flow. GROHE TurboStat compact cartridge with wax thermoelement. GROHE SafeStop safety button at 38°C. GROHE SafeStop Plus optional temperature limiter at 43°C included. GROHE DreamSpray perfect spray pattern. GROHE StarLight chrome finish. SpeedClean anti-lime system. Inner WaterGuide for a longer life. Twistfree to prevent hose from twisting. suitable for instantaneous heaters from 18 kW/h. minimum flow rate 7 l/min. min. recommended pressure 1.0 bar.
FinishChrome
Graden/a
Hot Water Connection Diameter13 mm
HWFU4.5
Ifc Export AsIfcPipeFitting
Ifc Export TypeIfcPipeFittingType
Industry Standardsn/a
KeynoteN13
LEED Creditn/a
Low Emitting MaterialNo
ManufacturerGrohe
Manufacturer NameGrohe
Masterformat Number01 52 19
Masterformat TitleSanitary Facilities
Materialn/a
ModelTempesta System 250 Cube
Model Number26691000
Model ReferenceTempesta System 250 Cube
NBS DescriptionShower heads
NBS Object NameGrohe - Shower heads
NBS Office Master Tagn/a
NBS Reference45-35-70/333
Nominal Depth0 mm
Nominal Height0 mm
Nominal Length0 mm
Percentage Of Recycled Contentn/a
Pipe MaterialGroheLimited-Pipework
Product Documentation Linkn/a
Production Year2020
Product Page URLn/a
Referenced Standardn/a
Replacement Costn/a
Shapen/a
Sizen/a
Spare Partsinfo-uk@grohe.com
Type Comments26691000
Type Name26691000
URLwww.grohe.com
Warranty Descriptionn/a
Warranty Duration Labor0
Warranty Duration Parts0
Warranty Duration UnitYears
Warranty Guarantor Laborinfo-uk@grohe.com
Warranty Guarantor Partsinfo-uk@grohe.com
WFU0
