MERLYN - Ionic by Merlyn Express Bifold Door

7.4k
0
- / 5
Rate this product

BS1192:4

Compliant

BSB

Compliant

Object Data

2 Revision

Last Updated

12/11/2021

Download BIM

Add to collection

Available for:

The Ionic Express Bifold Door is revolutionary in style with ease of function – it has stunning frameless glass and a discreet smooth action bifold hinge that makes it contemporary in both look and feel. The Express Bifold frame comes pre-assembled making it even easier to install!

Features:

Height: 1900mm
Ionic Patented Easy Fit System
MerShield Stayclear Easy Clean Glass Coating
6mm Toughened Safety Glass
Discrete Chrome Bifold Hinge
Frameless Bifold Door
Concealed Fixings
Exclusive Ionic Express tool & fittings kit provided
20 Year Guarantee
20mm Adjustment per wall profile

_AuthorSM
_Authorized Bybimstore
_Bim Spec Guid0
_BS Bible Version16
_Created Bywww.bimstore.co.uk
_Current Revision1
_distributed bywww.bimstore.co.uk
_Distributed Bywww.bimstore.co.uk
_Object User Guidewww.bimstore.co/products/merlyn-ionic-by-merlyn-express-bifold-door/document/object-user-guide
Accessibility Performancen/a
Adjustment/Wetroom Max990 mm
Adjustment/Wetroom Min950 mm
Assembly CodeD2010100
Asset TypeFixed
Base Offset120 mm
BIM Object NameCaseworkEnclosures_Merlyn_Ionic_Express_Bi_Fold_Door
Classification NameUniclass2015
Classification ValuePr_40_20_06_79
Code Performancen/a
ColorChrome
Constituentsn/a
Created Bybarratt@merlyn.ie
Created On11-11-2021-T09:00:00
Depth760 mm
DescriptionIonic Express Bifold Door
Documentation Certificateswww.bimstore.co/products/merlyn-ionic-by-merlyn-express-bifold-door/document/product-certificates
Documentation Installation Guidewww.bimstore.co/products/merlyn-ionic-by-merlyn-express-bifold-door/document/installation-guide
Documentation Literaturewww.bimstore.co/products/merlyn-ionic-by-merlyn-express-bifold-door/document/product-literature
Documentation Maintenancewww.bimstore.co/products/merlyn-ionic-by-merlyn-express-bifold-door/document/maintenance-information
Documentation Technicalwww.bimstore.co/products/merlyn-ionic-by-merlyn-express-bifold-door/document/technical-data-sheet
Drain Outlet Radius30 mm
Duration UnitYears
Expected Life0
FeaturesUnique Ionic fast fit system, Mershield stayclear easy clean glass coating, concealed fixings, discreet chrome bifold hinge, frameless bifold door
Glass Thickness6 mm
Graden/a
Handle Height950 mm
Height1900 mm
KeynoteN13/375
ManufacturerMerlyn
MaterialGlass and Chrome
Material Merlyn ChromeMerlyn - Chrome
Material Merlyn GlassMerlyn - Glass
Material Merlyn RubberMerlyn - Rubber
ModelA0300E0
Model NumberA0300
Model ReferenceA0300E0
NBS DescriptionShower Enclosures
NBS Object NameShower enclosures
NBS Office Master Tagn/a
NBS Reference45-35-70/332
Production Year2015
Referenced StandardCE Standards
Replacement Costn/a
ShapeRectangle
Side PanelNo
Side Panel Descriptionn/a
Side Panel Ref.n/a
Size1000x760
Spare Partsn/a
Support Offsets75 mm
Tag Numbern/a
Type CommentsIonic Express Bifold Door - 1000x760mm
Type NameIonic Express Bifold Door - 1000x760mm
URLmerlynshowering.com/
Warranty Description20 Year parts warranty
Warranty Duration Laborn/a
Warranty Duration Parts20
Warranty Duration UnitYears
Warranty Guarantor Laborn/a
Warranty Guarantor Parts20
Width1000 mm
