MERLYN - Ionic by Merlyn Express Quadrant Door

by MERLYN

Download Add to collection

Description

Ionic Express 1 Door Quadrant stands at 1900mm high with Mershield Stayclear coated 6mm glass, quick release rollers for easy clean and double fin seals for increased water retention.

Features:

Height: 1900mm

Ionic Patented Easy Fit System
Mershield StayClear Easy Clean Glass Coating
6mm Toughened Safety Glass
Smooth Action Extra Strong Rollers
Easy Clean Quick Release Rollers
Rollers come pre-assembled on the door
Concealed Fixings
Exclusive Ionic Express tool & fittings kit provided
20 Year Guarantee
20mm Adjustment per wall profile

Object Data

2 Revision

Last Updated

12/11/2021

Available Software

BS1192:4

Compliant

BSB

Compliant

EPD

Not Available

Accompanying literature

Installation Guide

Product Literature

Technical Data Sheet

Product Data Sheet

Object metadata

_AuthorSM
_Authorized Bybimstore
_Bim Spec Guid0
_BS Bible Version16
_Created Bywww.bimstore.co.uk
_Current Revision1
_Distributed Bywww.bimstore.co.uk
_Object User Guidewww.bimstore.co/products/merlyn-ionic-by-merlyn-express-quadrant-door/document/object-user-guide
Accessibility Performancen/a
Adjustment/Wetroom Max800 mm
Adjustment/Wetroom Min755 mm
Assembly CodeD2010100
Asset TypeFixed
Base Offset120 mm
BIM Object NameCaseworkEnclosures_Merlyn_Ionic_Express_2_Door_Quadrant
Classification NameUniclass2015
Classification ValuePr_40_20_06_79
Code Performancen/a
Colorn/a
Constituentsn/a
Created Bybarratt@merlyn.ie
Created On11-11-2021-T09:00:00
Depth800 mm
DescriptionIonic Express 2 Door Quadrant
Documentation Certificateswww.bimstore.co/products/merlyn-ionic-by-merlyn-express-quadrant-door/document/product-certificates
Documentation Installation Guidewww.bimstore.co/products/merlyn-ionic-by-merlyn-express-quadrant-door/document/installation-guide
Documentation Literaturewww.bimstore.co/products/merlyn-ionic-by-merlyn-express-quadrant-door/document/product-literature
Documentation Maintenancewww.bimstore.co/products/merlyn-ionic-by-merlyn-express-quadrant-door/document/maintenance-information
Documentation Technicalwww.bimstore.co/products/merlyn-ionic-by-merlyn-express-quadrant-door/document/technical-data-sheet
Drain Outlet Radius30 mm
Duration UnitYears
Expected Life0
FeaturesUnique Ionic fast fit system, Mershield stayclear easy clean glass coating, easy clean quick release rollers, double fin seal for increased water retention
Fixed Panel A221 mm
Glass Thickness6 mm
Graden/a
Handle Height950 mm
Height1900 mm
KeynoteN13/375
Length Adjustment0 mm
ManufacturerMerlyn
MaterialChrome
Material Merlyn ChromeMerlyn - Chrome
Material Merlyn GlassMerlyn - Glass
Material Merlyn RubberMerlyn - Rubber
ModelA0302A0
Model NumberA0302
Model ReferenceA0302A0
NBS DescriptionShower Enclosures
NBS Object NameShower enclosures
NBS Office Master Tagn/a
NBS Reference45-35-70/332
Production Year2015
Referenced StandardCE Standards
Replacement Costn/a
ShapeQuadrant
Size800 x 800mm
Spare Partsn/a
Support Offsets75 mm
Tag Numbern/a
Type CommentsIonic Express 800 2 Door Quadrant - 800 x 800mm
Type NameIonic Express 800 2 Door Quadrant - 800 x 800mm
URLmerlynshowering.com/
Warranty Description20 Year parts warranty
Warranty Duration Laborn/a
Warranty Duration Parts20
Warranty Duration UnitYears
Warranty Guarantor Laborn/a
Warranty Guarantor Parts20
Width800 mm
