Moulded Ogee Gutter

8.8k
0
5 / 5
Rate this product

BS1192:4

Compliant

BSB

Compliant

Object Data

2 Revision

Last Updated

25/06/2018

Download BIM

Add to collection

Available for:

The design of our Aluminium Moulded Ogee Gutters, also known as No. 46 or Type 46, is inspired by 19th Century cast iron gutters and these gutters are suitable for use on both period and contemporary properties. They offer the traditional look of cast iron gutters while providing all the benefits of aluminium guttering including being lightweight, environmentally friendly, and easy to install and maintain.

Object metadata

_AuthorTechnical Dept
_Authorized ByIan Holmes
_Bim Spec Guid0
_BS Bible Version15
_Created Bywww.Guttercrest.co.uk
_Current Revision1
_Distributed Bywww.bimstore.co.uk
Accessibility Performancen/a
Array Start525 mm
Assembly Coden/a
Asset TypeFixed
Available Colourswww.guttercrest.co.uk/images/lib/Guttercrest-Colour-Chart-Web-Version-Aug-2013_10.pdf
Back135 mm
BIM Object NameGuttercrest_Gutter_RainWaterSystem_MouldedOgeeGutter_Large
Bottom Rad44 mm
Brace Offset17 mm
Classification NamePr_65_50_35_06
Classification ValueUniclass2015
Code Performancen/a
ColorAny RAL, BS or Heritage (Textured) Colour
Compatible Downpipeswww.guttercrest.co.uk/images/lib/Guttercrest-Gutters-and-Downpipes_3.pdf
ConstituentsIntegral Jointing Straps & Cross-braces
Created ByInfo@Guttercrest.co.uk
Created On2018-05-05T00:00:00
Cross Brace Centres450 mm
Cross Brace Count0
Default Elevation1000 mm
DescriptionThe design of our Aluminium Moulded Ogee Gutters, also known as No. 46 or Type 46, is inspired by 19th Century cast iron gutters and these gutters are suitable for use on both period and contemporary properties. They offer the traditional look of cast iron gutters while providing all the benefits of aluminium guttering including being lightweight, environmentally friendly, and easy to install and maintain.
Dim 125 mm
Dim 262 mm
Dim 3101 mm
Dim 4141 mm
Documentation Certificatesn/a
Documentation Installation Guidewww.guttercrest.co.uk/images/lib/Fixing-Guidelines---Aluminium-moulded-ogee-gutters-large_1.pdf
Documentation Literaturewww.guttercrest.co.uk/aluminium-cast-moulded-ogee-gutters-guttering-gutter-no46-rainwater-goods.html
Documentation Maintenancen/a
Documentation Technicalwww.guttercrest.co.uk/images/lib/guttercrest-aluminium-moulded-ogee-guttering-system-large_2.pdf
Duration UnitYear
Expected Life0
FeaturesInternal & External Angles, Outlets & Stopends
FinishMill Finish or Polyester Powder Coated
Front125 mm
Grade1050
Gutter Sole115 mm
Gutter Width175 mm
Hole Cut2 mm
Hole Offset 175 mm
Hole Offset 215 mm
Hole Offset 32 mm
Ifc Export AsAluminium Eaves Gutter
Ifc Export TypeIfcBuildingElementProxyType
Is ExternalYes
KeynoteR10/350
ManufacturerGuttercrest Limited
Manufacturer NameGuttercrest Limited
MaterialAluminium
Material GradeAluminum 1050
Material Thickness2 mm
ModelMoulded Ogee
Model NumberMOG4
Model ReferenceLarge Moulded Ogee Gutter Range
NBS DescriptionAluminium Eaves Gutter
NBS Object NameGuttercrest - Aluminium Eaves Gutter
NBS Referencen/a
Nominal Depth175 mm
Nominal Height125 mm
Nominal Length3000 mm
Offstand15 mm
Product CodeMOG4
Production Year2018
Product Page Linkwww.guttercrest.co.uk/aluminium-cast-moulded-ogee-gutters-guttering-gutter-no46-rainwater-goods.html
Referenced StandardBS:9101 2017
Replacement Cost0
Spare Partsn/a
Top Rad44 mm
Type NameAluminium 175x125mm Moulded Ogee Gutter
Version90-05-35/320
Warranty Descriptioninfo@Guttercrest.co.uk
Warranty Duration Labor0
Warranty Duration Parts0
Warranty Duration UnitYear
Warranty Guarantor Laborn/a
Warranty Guarantor Partsinfo@Guttercrest.co.uk
