One Part Industrial Drain 300mm - Tile / Resin / Concrete
27.1k
0
- / 5Rate this product
Available for:
This Download Contains the BLÜCHER® Industrial One-part drains – size 300 mm. Flow rate up from up to 6.8 ltr/sec.
Select the product(s) based on outside (visible) dimension, flow rate, and / or item number, to upload in your project.
- Horizontal and Vertical outlet, 110 and 160 mm
- For concrete, tiled and resin floors
Upper frames models Square 403 and Round 503
Drains 726 / 760 / 763 / 766
- The product is made from 1.5 mm acid-pickled stainless steel.
- 4 Grating options load class up to 10.000 kg
- Designed in accordance with EN1253.
Key Component Features:
- User selectable Drain
- User selectable Gratings
- User selectable Watertrap
- User selectable Filter Basket
- Automated product codes
- Pre-selected concrete cut out / base concrete slab option for installation purpose
Products: 726.403.110, 763.403.110, 760.403.110, 760.403.160, 766.403.110, 766.403.160, 726.503.110, 763.503.110, 760.503.110, 760.503.160, 766.503.110, 766.503.160
Search Opt.: blucher
