PIR presence detectors (EBDMR-PRM-DD-AD)

by CP Electronics

Download Add to collection

Description

Part of our mid-range, ceiling, flush mounted detectors. A superior detection pattern using a high performance faceted lens suitable for use in open plan spaces or where a larger detection range is required.

Key features:

New mid-range lens with concentric lens facets for improved detection
360° presence and absence detection
Ideal for open plan offices
IP40 rated
Available in a wide range of RAL colours.

Object Data

1 Revision

Last Updated

06/11/2019

Available Software

BS1192:4

Compliant

BSB

Compliant

EPD

Not Available

Accompanying literature

Product Data Sheet

Object metadata

_AuthorIan Holmes
_Authorized ByIan Holmes
_Bim Spec Guid0
_BS Bible Version15
_Created Bywww.bimstore.co.uk
_Current Revision1
_Distributed Bywww.bimstore.co.uk
Accessibility Performancen/a
Apparent Load0 VA
Assembly CodeD50
Asset TypeFixed
BIM Object NameCPElectronics_ElectricalFixtures_PresenceDetector_(EBDMR-AD)
Classification NameUniclass2015
Classification ValuePr_70_70_48_26
Code Performancen/a
ColorWhite RAL9003
ComplianceEMC-2004/30/EU; LVD-2014/35/EU
Constituentsn/a
Control Method1-10V Analogue Dimming
Coverage360.00 °
Created Byinfo@cpelectronics.co.uk
Created On2018-06-18T09:00:00
Default Elevation0 mm
DescriptionCeiling presence detector
Detector MaterialFlame Retardant ABS
Device Ballast Controlup to 10 drivers/ballasts
Documentation Certificateswww.cpelectronics.co.uk/product-guides
Documentation Installation Guidewww.cpelectronics.co.uk/product-guides
Documentation Literaturewww.cpelectronics.co.uk/product-guides
Documentation Maintenancewww.cpelectronics.co.uk/product-guides
Documentation Technicalwww.cpelectronics.co.uk/product-guides
Duration UnitYears
Expected Life0
External Depth12 mm
FeaturesNew mid-range lens with concentric lens facets for improved detection. 360° presence and absence detection. Ideal for open plan offices. IP40 rated. Available in a wide range of RAL colours.
Field Of Vision2.8m x 15m
Finishn/a
Frequency50Hz
Graden/a
Humidity5 to 95% non-condensing
Ifc Export AsIfcJunctionBox
Ifc Export TypeIfcJunctionBoxTypeEnum.POWER
InsulationClass 2
IP RatingIP40
KeynoteW41/320
Load10 A
ManufacturerCP Electronics
Manufacturer NameCP Electronics
MaterialFlame retardant ABS and PC/ABS
ModelEBDMR-AD
Model NumberEBDMR-AD
Model ReferenceEBDMR-AD
Mounting Height2800 mm
NBS DescriptionElectrical low mounted way-guidance lighting module housings
NBS Object NameCP Electronics - Electrical low mounted way-guidance lighting module housings
NBS Office Master Tagn/a
NBS Reference90-60-50/480
Nominal Depth76 mm
Nominal Height0 mm
Nominal Length77 mm
Power Consumption Off724mW
Power Consumption On0mW
Production Year2018
Recessed Depth65 mm
Referenced Standardn/a
Replacement Costn/a
ShapeCylindrical
Sizen/a
Spare Partsn/a
Temperature RangeMinus 10°C to + 35°C
Time Out Range10s - 99m
Type CommentsEBDMR-AD
Type NameEBDMR-AD
URLwww.cpelectronics.co.uk/
Voltage230 V
Warranty Descriptionn/a
Warranty Duration Labor5
Warranty Duration Parts5
Warranty Duration UnitYears
Warranty Guarantor Laborinfo@cpelectronics.co.uk
Warranty Guarantor Partsinfo@cpelectronics.co.uk
Weight0.10 kg
