Potable Vessel (Reflex)
Unapproved
11.1k
0
5 / 5Rate this product
Available for:
Application
Potable Vessels are commonly used in systems with an Unvented Water Heater or a Pumped System. These units are a low-cost solution for potable water, water heating & hydro-pneumatic well applications. Water does not flow through this vessel. The DE range is fitted with a bladder, which can be replaced from 50 liters on, and is ideal for use in water systems with higher corrosion resistance requirements, as suitable for brine circuits in heat pump systems.
Design
Manufactured in carbon steel with a two or three part weld construction. Pre-pressurised air chamber with synthetic rubber compound bladder. Sizes 60 to 1000 litres (except 140 litres) have a replaceable bladder.
The internal surfaces of the vessel in contact with the water are coated against corrosion. External surfaces have a blue durable powder coated finish. Suitable for temperatures up to 70°C, resistant to ethylene or propylene glycol mixtures and has low gas permeability.
Altecnic expansion vessels are all tested according to the Pressure Systems Directive.
This download contains
1 Mechanical Equipment Family with thirty nine types;
from PV2W - 2L Potable Vessel up to PV1000W - 1000L Potable Vessel
COBie and NBSCreate Parameters
Altecnic BIM Userguide
Read more
