T DAVIT Variable Winch (TDVW)

by Reid Lifting

Download Add to collection

Description

Our TDAVIT – TDVW is lightweight, portable and has been designed to meet customer needs where the lifting and moving of equipment in tight spaces is a challenge.

A truly unique product, it offers a lifting capacity of up to 300kg in combination with a geared trolley which is able to traverse the beam, in addition to 360 degree rotation under load. It is very well suited to plant rooms, engine rooms and kiosks or anywhere where space is a premium and flexibility in moving loads is needed.

Object Data

1 Revision

Last Updated

23/02/2023

Available Software

BS1192:4

Compliant

BSB

Compliant

EPD

Not Available

Accompanying literature

Object User Guide

Product Literature

Technical Data Sheet

Product Data Sheet

Object metadata

_AuthorRL
_Authorized Bybimstore
_Bim Spec Guid0
_BS Bible Version17
_Created Bywww.bimstore.co/
_Current Revision1
_Distributed Bywww.bimstore.co/
_Object User Guidewww.bimstore.co/products/reid-lifting-tdvw/document/object-user-guide
Accessibility Performancen/a
Assembly CodeD1010300
Asset TypeFixed
BIM Object NameREIDLifting_TDAVIT_TDVW_VariableWinch
Bridge Mount Socket SBMA0500BridgeMountSocket : SBMA0500
Bridge Mount Socket SBMG0500BridgeMountSocket : SBMG0500
Bridge Mount Socket SBMS0500BridgeMountSocket : SBMS0500
Classification NameUniclass2015
Classification ValueTE_30_30_10
Code Performancen/a
ColorGrey & Blue
Constituentsn/a
Created Byenquiries@reidlifting.com
Created On2023-03-01T09:00:00
DescriptionOur TDAVIT – TDVW is lightweight, portable and has been designed to meet customer needs where the lifting and moving of equipment in tight spaces is a challenge.
Documentation Certificateswww.bimstore.co/products/reid-lifting-tdvw/document/product-certificates
Documentation Installation Guidewww.bimstore.co/products/reid-lifting-tdvw/document/installation-guide
Documentation Literaturewww.bimstore.co/products/reid-lifting-tdvw/document/product-literature
Documentation Maintenancewww.bimstore.co/products/reid-lifting-tdvw/document/maintenance-information
Documentation Technicalwww.bimstore.co/products/reid-lifting-tdvw/document/technical-data-sheet
Duration UnitYears
Expected Life0
Featuresn/a
FinishPainted Steel
Graden/a
Handle Length575 mm
Ifc Export AsIfcBuildingElementProxy
Ifc Export TypeIfcBuildingElementProxy
KeynoteN
ManufacturerREID Lifting
Manufacturer NameREID Lifting
MaterialSteel
ModelTDAVIT TDVW - Variable Winch
Model NumberTDVWA31200
Model ReferenceTDAVIT TDVW - Variable Winch
NBS DescriptionConstruction lifts
NBS Noten/a
NBS Object NameREID Lifting - Construction lifts
NBS Office Master Tagn/a
NBS Referencen/a
Nominal Depth0 mm
Nominal Height0 mm
Nominal Length0 mm
Production Year2023
Referenced Standardn/a
Replacement Costn/a
Shapen/a
Side Mount Socket SSMA0500SideMountSocket : SSMA0500
Side Mount Socket SSMG0500 V2SideMountSocket : SSMG0500V2
Side Mount Socket SSMG1000SideMountSocket : SSMG1000
Side Mount Socket SSMS0500 V2SideMountSocket : SSMS0500V2
Side Mount Socket SSMS1000SideMountSocket : SSMS1000
Sizen/a
Socket Pedestals SP0500SocketPedestals : SP0500
Socket Pedestals SP0800SocketPedestals : SP0800
Socket Pedestals SP1100SocketPedestals : SP1100
Spare Partsenquiries@reidlifting.com
Top Beam Length1463 mm
Top Mount Socket STMA0500TopMountSocket : STMA0500
Top Mount Socket STMG0500 V2TopMountSocket : STMG0500V2
Top Mount Socket STMG1000TopMountSocket : STMG1000
Top Mount Socket STMS0500 V2TopMountSocket : STMS0500V2
Top Mount Socket STMS1000TopMountSocket : STMS1000
Type CommentsTDVWA31200
Type NameTDAVIT TDVW - Variable Winch
URLuk.reidlifting.com/
Vertical Beam Length1369 mm
Warranty Descriptionn/a
Warranty Duration Labor0
Warranty Duration Parts0
Warranty Duration UnitYears
Warranty Guarantor Laborenquiries@reidlifting.com
Warranty Guarantor Partsenquiries@reidlifting.com
