Scene select plates (VITP7-4SC)

by CP Electronics

Download Add to collection

Description

Scene selection allows the recall of pre-programmed lighting levels to create different moods or to suit different uses within an environment.

When used in conjunction with VITP7-MB and suitable dimming luminaires different lighting scenes can be achieved for applications such as classrooms and meeting rooms.

Object Data

1 Revision

Last Updated

06/11/2019

Available Software

BS1192:4

Compliant

BSB

Compliant

EPD

Not Available

Accompanying literature

Product Data Sheet

Object metadata

_AuthorIan Holmes
_Authorized ByIan Holmes
_Bim Spec Guid0
_BS Bible Version15
_Created Bywww.bimstore.co.uk
_Current Revision1
_Distributed Bywww.bimstore.co.uk
Accessibility Performancen/a
Assembly CodeD50
Asset TypeFixed
Back Box Width66 mm
BIM Object NameCPElectronics_ElectricalEquipment_4SCScenePlate_(VITP7-4SC)
Classification NameUniclass2015
Classification ValuePr_70_70_48_28
Code Performancen/a
ColorWhite RAL9003
ComplianceEMC-89/336/EEC; LVD-72/23/EEC
Constituentsn/a
Created Byinfo@cpelectronics.co.uk
Created On2018-06-18T09:00:00
Default Elevation0 mm
DescriptionScene select plates
Detector MaterialFlame Retardant ABS
Documentation Certificateswww.cpelectronics.co.uk/product-guides
Documentation Installation Guidewww.cpelectronics.co.uk/product-guides
Documentation Literaturewww.cpelectronics.co.uk/product-guides
Documentation Maintenancewww.cpelectronics.co.uk/product-guides
Documentation Technicalwww.cpelectronics.co.uk/product-guides
Duration UnitYears
Expected Life0
FeaturesScene selection allows the recall of pre-programmed lighting levels to create different moods or to suit different uses within an environment.
Finishn/a
Fixing Centres60.3mm
Graden/a
Humidity5 to 95% non-condensing
Ifc Export AsIfcJunctionBox
Ifc Export TypeIfcJunctionBoxTypeEnum.POWER
IP RatingIP65
KeynoteW41/320
Load0 A
ManufacturerCP Electronics
Manufacturer NameCP Electronics
MaterialFlame retardant ABS and PC/ABS
ModelVITP7
Model NumberVITP7-4SC
Model ReferenceVITP7
NBS DescriptionCP Electronics - Electrical low mounted way-guidance lighting supply units
NBS Object NameCP Electronics - Electrical low mounted way-guidance lighting module housings
NBS Office Master Tagn/a
NBS Reference90-60-50/485
Nominal Depth18 mm
Nominal Height86 mm
Nominal Length86 mm
Power Consumption Off0mW
Power Consumption On0mW
Production Year2018
Recessed Depth13 mm
Recess Required25 mm
Referenced Standardn/a
Replacement Costn/a
ShapeRectangle
Sizen/a
Spare Partsn/a
Temperature RangeMinus 10°C to + 35°C
Terminal Capacity1.5mm2
Type CommentsVITP7-4SC
Type NameVITP7-4SC
URLwww.cpelectronics.co.uk/
Voltage12V
Warranty Descriptionn/a
Warranty Duration Labor5
Warranty Duration Parts5
Warranty Duration UnitYears
Warranty Guarantor Laborinfo@cpelectronics.co.uk
Warranty Guarantor Partsinfo@cpelectronics.co.uk
Wattage0 W
Weight0.02 kg
