Silent MV

by EnviroVent

Download Add to collection

Description

Presenting the world’s most silent in-line fan range in their class, the Silent MV range creates a quantum leap forward in technology to improve the acoustic performance of up to 12 dB(A) compared with similar products on the market.

The Silent MV range is the result of an intense R&D, technological and economic investment to ensure that you can be guaranteed of a product range that provides exceptional performance with significant noise reduction.

Following extensive aerodynamic testing, we have been able to not only reduce the amount of noise produced but also ensure that the noise level that is actually emitted is at a far lower frequency, providing a quiet and ambient environment.

By installing the Silent MV, you will never experience the disturbance of noisy ventilation again.

Key Features

IP44 Rated
5 Year Warranty (High quality products for peace of mind, saving time, money and hassle.)

Product Codes

Product Code	Product Name	Product Description	Application
SILENTMV160/100S	Silent MV 160/100S	Ultra quiet in-line fan - ⌀100mm	Residential Ventilation
SILENTMV160/100T*	Silent MV 160/100T*	Ultra quiet in-line fan with adjustable timer- ⌀100mm	Residential Ventilation
SILENTMV250/100	Silent MV 250/100	Ultra quiet in-line fan - ⌀100mm	Residential Ventilation
SILENTMV250/100T*	Silent MV 250/100T*	Ultra quiet in-line fan with adjustable timer- ⌀100mm	Residential Ventilation
SILENTMV350/125	Silent MV 350/125	Ultra quiet in-line fan - ⌀125mm	Residential Ventilation
SILENTMV350/125T*	Silent MV 350/125T*	Ultra quiet in-line fan with adjustable timer- ⌀125mm	Residential Ventilation
SILENTMV500/150	Silent MV 500/150	Ultra quiet in-line fan - ⌀125mm	Commercial Ventilation
SILENTMV500/150T*	Silent MV 500/150T*	Ultra quiet in-line fan with adjustable timer- ⌀125mm	Commercial Ventilation
SILENTMV800/200	Silent MV 800/200	Ultra quiet in-line fan - ⌀200mm	Commercial Ventilation
SILENTMV800/200T*	Silent MV 800/200T*	Ultra quiet in-line fan with adjustable timer- ⌀200mm	Commercial Ventilation
SILENTMV1000/200	Silent MV 1000/200	Ultra quiet in-line fan - ⌀200mm	Commercial Ventilation
SILENTMV1000/200T*	Silent MV 1000/200T*	Ultra quiet in-line fan with adjustable timer- ⌀200mm	Commercial Ventilation
SILENTMV1300/250	Silent MV 1300/250	Ultra quiet in-line fan - ⌀250mm	Commercial Ventilation

Object Data

1 Revision

Last Updated

11/03/2020

Available Software

BS1192:4

Compliant

BSB

Compliant

EPD

Not Available

_AuthorEnvirovent
_Authorized Bybimstore
_Bim Spec Guid0
_BS Bible Version16
_Created Byinfo@envirovent.com
_Current Revision1
_Distributed Bywww.bimstore.co
6 Monthly MaintenanceClean filters with vacuum cleaner
A568 mm
Accessibility PerformanceSufficient clearance room needed for regular inspection
Airflow Rate Range306.0 L/s
Annual MaintenanceFilters should be replaced
Assembly CodeD3040100
Assembly PlaceFACTORY
Asset TypeFixed
BIM Object NameEnvirovent_MechanicalEquipment_Silent_Inline_ExtractFan_1000-200
Body MaterialWhite
C327 mm
CE ApprovalYes
Classification NameUniclass2015
Classification ValuePr_65_67_29_52
Clearance Zone MaterialClearanceZone
Code Performancen/a
ColorWhite
ConstituentsAdjustable Two Speed Motor, Sealed For Life Ball Bearings, 360° rotating connection box
Created Byinfo@envirovent.com
Created On2020-03-01T09:00:00
D264 mm
DescriptionSilent MV 1000/200 In-line Fan
Documentation Certificateswww.envirovent.com
Documentation Installation Guidewww.envirovent.com
Documentation Literaturewww.envirovent.com
Documentation Maintenancewww.envirovent.com
Documentation Technicalwww.envirovent.com
Duct Diam200 mm
Duct Rad100 mm
Duration UnitYears
Expected Life10
F340 mm
FeaturesIn-line Duct Fans - Ultra quiet, two speed motor
FinishPlastic
Fitting TypeIgnore
Flow0.0 L/s
Graden/a
Gross Weight8.70 kg
H164 mm
Has Protective EarthNo
Ifc Export AsIfcFan
Ifc Export TypeNOTDEFINED
IP Code44
ISO140001Yes
ISO90001Yes
KeynoteT
ManufacturerEnvirovent
Manufacturer AddressEnviroVent House, Hornbeam Business park, Harrogate, HG2 8PA
Manufacturer E Mailinfo@envirovent.com
Manufacturer NameEnvirovent
Manufacturer Telephone01423810810
MaterialPlastic Material With RUbber Gaskets
ModelSilent MV 1000/200 In-line Fan
Model NumberSilent MV 1000/200 In-line Fan
Model ReferenceSilent MV 1000/200 In-line Fan
NBS DescriptionMixed Flow Fans
NBS Object NameEnvirovent-Mixed Flow Fans
NBS Office Master Tagn/a
NBS Reference90-45-30/340
Nominal Depth327 mm
Nominal Frequency Range50
Nominal Height264 mm
Nominal Length568 mm
Number Of Poles1
Passive House ApprovalNo
Pressure CurveAvailable on www.envirovent.com
Production Year2020
Quantity1
Quarterly MaintenanceClean filters with vacuum cleaner
R132 mm
Rated Current1 A
Rated Voltage230 V
Red Dot Design AwardNo
Referenced Standardn/a
Replacement Costn/a
SAP ApprovalNo
ShapeCylinder
Size568 x 327 x 264
Spare Partsinfo@envirovent.com
StatusNew
Supply Phase1
Temperature Rangeup to 60°C
Type CommentsSilent MV 1000/200 In-line Fan
Type ImageEnvirovent_MechanicalEquipment_Silent_Inline_ExtractFan_1000-200.jpg
Type NameSilent MV 1000/200 In-line Fan
URLwww.envirovent.com/
Warranty DescriptionThe unit shall be covered by a 5 year warranty.
Warranty Duration Labor0
Warranty Duration Parts5
Warranty Duration UnitYears
Warranty Guarantor Laborinfo@envirovent.com
Warranty Guarantor Partsinfo@envirovent.com
