Slimline Décor - Shaver Sockets

by Deta Electrical Co. Ltd.

Download Add to collection

Description

Slimline Décor offers a comprehensive range of accessories available in a choice of Chrome or Satin Chrome finishes with either black or white moulded inserts. With matching metal rockers on all switched accessories, Slimline Décor provides elegance and sophistication to any modern domestic or commercial building.

Dual voltage 240V/115V, Grey font engraving, Clear terminal markings, Colour coded terminals, Neon indicator, Terminals have large lead-ins one size 4mm screwdriver needed.

Products in the Slimline Décor range are guaranteed for 25 years (2 years for electronic products).

This download is for the Slimline Decor - Shaver Sockets Range and includes the following types;

S1305CH/SC - Dual voltage with neon

Object Data

1 Revision

Last Updated

10/07/2023

Available Software

BS1192:4

Compliant

BSB

Compliant

EPD

Not Available

Accompanying literature

Installation Guide

Product Literature

Technical Data Sheet

Product Data Sheet

Object metadata

_AuthorIan Holmes
_Authorized ByKris Atkinson
_Bim Spec Guid0
_BS Bible Version14
_Created Bywww.bimstore.co.uk
_Current Revision1
_Distributed Bywww.bimstore.co.uk
Accessibility Performancen/a
Assembly CodeD5020120
Asset TypeFixed
Back Box Depth46 mm
BIM Object NameElectricalFixtures_DetaElectrical_SlimlineDecor_ShaverSockets
Classification NameUniclass2015
Classification ValuePr_75_51_17_50
Code Performancen/a
ColorChrome
Constituentsn/a
Created Bysales@detaelectrical.co.uk
Created On2017-04-27T00:00:00
Default Elevation1219 mm
DescriptionDual voltage with neon
Documentation Certificatesn/a
Documentation Installation Guidespecifi.bimstore.co.uk/document/share/2157
Documentation Literaturespecifi.bimstore.co.uk/document/share/2157
Documentation Maintenancen/a
Documentation Technicalspecifi.bimstore.co.uk/document/share/2157
Duration UnitYears
Expected Life0
FeaturesDual voltage 240V/115V, Grey font engraving, Clear terminal markings, Colour coded terminals, Neon indicator, Terminals have large lead-ins one size 4mm screwdriver needed.
Finishn/a
Graden/a
Height146 mm
Ifc Export AsIfcJunctionBoxTypeEnum.POWER
Ifc Export TypeIfcJunctionBox
KeynoteV
ManufacturerDeta Electrical
Manufacturer NameDeta Electrical
MaterialChrome
ModelSlimline Décor - Shaver Sockets
Model Numbers1305CH
Model ReferenceSlimline Décor - Shaver Sockets
NBS DescriptionManual control switches
NBS Object NameDeta Electrical - Manual control switches
NBS Office Master Tagn/a
NBS Referencen/a
Nominal Depth7 mm
Nominal Height146 mm
Nominal Length86 mm
Production Year2017
RedDetaElectrical_RedLight
Referenced StandardBS 4573, BS 60742
Replacement Costn/a
ShapePortrait
Size86mm x 146mm
Spare Partsn/a
Thickness7 mm
Type CommentsShaverSockets - s1305CH
Type NameShaverSockets - s1305CH
Unit MaterialDetaElectrical_Chrome
URLwww.detaelectrical.co.uk/
Warranty DescriptionProducts in the Slimline range are guaranteed for 25 years (2 years for electronic products).
Warranty Duration Laborn/a
Warranty Duration Parts2
Warranty Duration UnitYears
Warranty Guarantor Laborsales@detaelectrical.co.uk
Warranty Guarantor Partssales@detaelectrical.co.uk
Width86 mm
