Softline Deco Radiator

by Stelrad Radiators Ltd

Download Add to collection

Description

The Softline Deco is the epitome of minimalist, contemporary design. With a premium exterior look and Stelrad manufacturing quality inside, it’s a clear choice for the interior-conscious homeowner.

Avaiable in K1 and K2 variations and lengths 400mm - 2000mm and heights 300mm, 450mm, 600mm

Click here to view our interactive brochure

Object Data

1 Revision

Last Updated

21/02/2024

Available Software

BS1192:4

Compliant

BSB

Compliant

EPD

Not Available

Accompanying literature

Object User Guide

Product Literature

Technical Data Sheet

Product Data Sheet

Object metadata

_AuthorJY
_Authorized Bybimstore
_Bim Spec Guid0
_BS Bible Version15
_Created Bywww.bimstore.co/
_Current Revision2
_Distributed Bywww.bimstore.co/
Access Clearance Bottom0.000000000000 mm
Access Clearance Front0.000000000000 mm
Access Clearance Left0.000000000000 mm
Access Clearance Rear0.000000000000 mm
Access Clearance Right0.000000000000 mm
Access Clearance Top0.000000000000 mm
Accessibility Performancewww.stelrad.com/support-information/dop/
Air VentNo
Assembly CodeD3020
Asset TypeFixed
BIM Object NameMechanical_Equipment-Radiators-Stelrad-Softline_Deco_K1
Bracket A150.000000000000 mm
Bracket B60.000000000000 mm
Bracket C17.000000000000 mm
Casing MaterialMild Steel
Classification NameUniclass2015
Classification ValuePr_70_60_36_73
ColorWhite (RAL 9016)
ColourWhite (RAL 9016)
Connector Dia15.000000000000 mm
Connector Dia Calc7.500000000000 mm
Created Byinfo@stelrad.com
Created OnFeb16
Depth83.000000000000 mm
DescriptionThe Softline Deco is the epitome of minimalist, contemporary design. With a premium exterior look and Stelrad manufacturing quality inside, it’s a clear choice for the interior-conscious homeowner.
Documentation Certificateswww.stelrad.com/support-information/dop/
Documentation Literaturespecifi.bimstore.co.uk/document/share/1544
Documentation Technicalspecifi.bimstore.co.uk/document/share/1544
Drain TapNo
Duration UnitYears
Expected Life0
FinishPainted
FinnedYes
GradeK1
Gross Weight14.13
Heat Emitter MaterialMild Steel
Heat Output Btu/hr1604
Heat Output Watts470
Heat reflectorNo
Heat Transfer MediumConvection
Height300.000000000000 mm
Height From Floor0.000000000000 mm
Inlet GrilleNo
Integral Lockshield ValveNo
Integral Regulating ValveNo
Integral TRVNo
KeynoteT30/350
Length1000.000000000000 mm
Location of ManufacturerRotherham, S64 8BN, United Kingdom
ManufacturerStelrad Ltd
MaterialMild Steel
Maximum Operating Pressure8
Maximum Operating TemperatureN/A
Maximum Test Pressure10.5
Middle BracketNo
ModelStelrad Softline Deco
Model NumberStelrad Softline Deco
Mounting TypeWall Mounted
NBS DescriptionRadiators
NBS Object NameRadiators
NBS Office Master Tagn/a
NBS Reference90-40-35/405
Number of PanelsN/A
Number of SectionsN/A
Outlet GrilleNo
Overall Height300.000000000000 mm
Overall Length1000.000000000000 mm
Pipe Connections Size15mm
Possible Connections PositionsBBOE
Product Literature2jomhg1cupfs2jxnrb3gelkt.wpengine.netdna-cdn.com/wp-content/uploads/2015/10/Softline-Deco-Tech-Bro1.pdf
Product Model Number84301110
Product RangeStelrad Softline Deco
Production Year2016
Radiator MaterialStelrad - RAL 9016
Reference StandardEN 442 Certification Data - CETIAT tested in accordance with BS EN 442
Seam TypeN/A
ShapeRectangle (Horizontal)
Shipping WeightN/A
Size300 x 1000mm
TypeConvector
Type CommentsK1 - 300x1000mm
Type NameK1 - 300x1000mm
UIN84301110
URLwww.stelrad.com/
Wall BracketsYes
Warranty DescriptionInfo@stelrad.com
Warranty Duration Parts15
Warranty Duration UnitYears
Warranty Guarantor LaborInfo@stelrad.com
Warranty Guarantor PartsInfo@stelrad.com
Water Content1.81
