Softline Deco Vertical Radiator

by Stelrad Radiators Ltd

Download Add to collection

Description

The subtle architectural look and feel of the Softline Deco Vertical is combined with value, range and availability to give you sophisticated designer styling for any room, commercial or domestic at affordable prices.

Avaiable in K2 variations and lengths 400mm - 600mm and 1800mm height.

This download includes all available types for the Softline Deco Vertical radiator.

Click here to view our interactive brochure

Object Data

1 Revision

Last Updated

20/02/2024

Available Software

BS1192:4

Compliant

BSB

Compliant

EPD

Not Available

Accompanying literature

Object User Guide

Product Literature

Technical Data Sheet

Product Data Sheet

Object metadata

_authorized byKris Atkinson
_BIMspec_GUID0
_created byKris Atkinson
_current revision1
_distributed bywww.bimstore.co.uk
Access Clearance Bottom0 mm
Access Clearance Front0 mm
Access Clearance Left0 mm
Access Clearance Rear0 mm
Access Clearance Right0 mm
Access Clearance Top0 mm
Air VentYes
Array Calc6
Assembly CodeD3020
Asset TypeFixed
Bracket Height Calc1775 mm
Bracket Offset100 mm
Casing MaterialMild Steel
Classification NameUniclass2015
Classification ValuePr_70_60_36_73
ColorWhite (RAL 9016)
ColourWhite (RAL 9016)
Connector Dia15 mm
Connector Dia Calc8 mm
Created Byinfo@stelrad.com
Created OnFeb16
Depth103 mm
DescriptionThe Softline Deco is the epitome of minimalist, contemporary design. With a premium exterior look and Stelrad manufacturing quality inside, it’s a clear choice for the interior-conscious homeowner.
Documentation Certificateswww.stelrad.com/support-information/dop/
Documentation Installation Guidewww.stelrad.com/support-information/dop/
Documentation Literaturespecifi.bimstore.co.uk/document/share/1544
Documentation Maintenancewww.stelrad.com/support-information/dop/
Documentation Technicalspecifi.bimstore.co.uk/document/share/1544
Drain TapNo
Duration UnitYears
Embodied CarbonN/A
Expected Life0
FinishPainted
FinnedYes
GradeK2
Gross Weight42.12
Heat Emitter MaterialMild Steel
Heat Output Btu/hr5036
Heat Output Watts1476
Heat reflectorNo
Height1800 mm
Height From Floor150 mm
Inlet GrilleNo
Integral Lockshield ValveNo
Integral Regulating ValveNo
Integral TRVNo
KeynoteT30/350
Length400 mm
Location of ManufacturerRotherham, S64 8BN, United Kingdom
ManufacturerStelrad Ltd
MaterialMild Steel
Maximum Operating Pressure8
Maximum Operating TemperatureN/A
Maximum Test Pressure13.5
ModelStelrad Softline Deco V
Model NumberStelrad Softline Deco V
Mounting TypeWall Mounted
NBS Object NameRadiators
NBS Reference90-40-35/405
Number of PanelsN/A
Number of SectionsN/A
Outlet GrilleNo
Overall Height1800 mm
Overall Length400 mm
Pipe Connections Size15mm
Possible Connections PositionsTop or Bottom
Product Literature2jomhg1cupfs2jxnrb3gelkt.wpengine.netdna-cdn.com/wp-content/uploads/2015/10/Softline-Deco-Tech-Bro1.pdf
Product Model Number87222618
Product RangeStelrad Softline Deco V
Production Year2016
Radiator MaterialStelrad - RAL 9016
Reference StandardEN 442 Certification Data - CETIAT tested in accordance with BS EN 442
Seam TypeSeam Weld
ShapeRectangular (Vertical)
Shipping WeightN/A
Size1800 x 600mm
Spare PartsN/A
Tapping Centres from Wall76 mm
Thermal OutputN/A
TypeK2 Vertical
Type CommentsK2 - 1800x600mm
Type NameK2 - 1800x600mm
UIN87222618
URLwww.stelrad.com/
Wall BracketsYes
Warranty Description15 Years
Warranty Duration UnitYears
Warranty Guarantor Laborinfo@stelrad.com
Warranty Guarantor Partsinfo@stelrad.com
Water Content6.36
