Sombrero Ring LED Pendant

Object metadata

• _AuthorAM
• _Authorized Bybimstore
• _Bim Spec Guid0
• _BS Bible Version16
• _Created Bywww.bimstore.co
• _Current Revision1
• _Distributed Bywww.bimstore.co
• _Object User Guidewww.bimstore.co/products/sombrero-ring/document/object-user-guide
• Accessibility Performancen/a
• Apparent Load0.000000000000 VA
• Assembly CodeD5020200
• Asset TypeFixed
• BIM Object NameSynergy_LightingFixtures_FeatureLED_SombreroRing_CeilingMounted_LowGlare
• Black Finish1
• Body Depth5.000000000000 mm
• Body MaterialSynergy - Aluminium - Powder Coated - RAL 9005
• Classification NameUniclass2015
• Classification ValuePr_70_70_48_85
• Code Performancen/a
• ColorBlack
• Color Filter16777215
• Colour Rendering Index>80
• Constituentsn/a
• Created Bysales@synergy.gb.net
• Created On2020-08-10T09:00:00
• DALI2
• Default Elevation1219.200000000000 mm
• Delivered Lumens6130
• Depth100.000000000000 mm
• DescriptionCircular ring LED pendant. The Sombrero Ring LED pendant is perfect for making a statement in large commercial spaces, such as receptions, meeting areas and stairwells. Commercial LED ring pendants are very trendy at the moment and we have supplied many to offices, schools and even leisure centres in London. The Sombrero LED Ring Pendant is also available with surface mounted and recessed options. The colour temperature is 4000k as standard - 3000k available on request. 75mm profile height. The Sombrero LED Ring Pendant can be ordered with a UGR19 low glare diffuser and come in a huge range of colour options.
• Diameter1200.000000000000 mm
• Diffuser MaterialSynergy - Glass - Luminous
• Dimming Lamp Color Temperature Shift0
• Documentation Certificateswww.bimstore.co/products/sombrero-ring/document/product-certificates
• Documentation Installation Guidewww.bimstore.co/products/sombrero-ring/document/installation-guide
• Documentation Literaturewww.bimstore.co/products/sombrero-ring/document/product-literature
• Documentation Maintenancewww.bimstore.co/products/sombrero-ring/document/maintenance-information
• Documentation Technicalwww.bimstore.co/products/sombrero-ring/document/technical-data-sheet
• Duration UnitYear
• Emit from Circle Diameter609.600000000000 mm
• Emit Shape Visible in RenderingYes
• Expected Life0
• Featuresn/a
• FinishBlack
• Finish Option1
• Fixed1
• Graden/a
• Height75.000000000000 mm
• Ifc Export AsIfcLamp
• Ifc Export TypeIfcLampTypeEnum.LED
• Inrush Current20A / 100
• IP RatingIP20/IP20
• KeynoteV90/510
• LampLED
• Length1200.000000000000 mm
• Light Source Symbol Size609.600000000000 mm
• Luminaire Efficacy95.8 llm/cw
• Mac Adam3
• Mains Frequency50.000000000000 Hz
• Mains Voltage220.000000000000 V
• ManufacturerSynergy
• Manufacturer NameSynergy
• MaterialAluminium
• ModelSombrero Ring
• Model NumberSombrero Ring
• Model ReferenceLED Linear Surface Mounted Luminaire
• NBS DescriptionSurface luminaries
• NBS Object NameSynergy - Surface luminaries
• NBS Office Master Tagn/a
• NBS Reference90-60-50/390
• Nominal Depth100.000000000000 mm
• Nominal Height75.000000000000 mm
• Nominal Length1200.000000000000 mm
• Nominal Weight0.000000000000 kg
• Number Of Drivers2
• Power Factor>0.9
• Production Year2020
• Radius600.000000000000 mm
• Rated Life50,000hrs L80 / B20
• Referenced Standardn/a
• Replacement Costn/a
• ShapeCircular
• Size1200mm(dia) x 75mm(h) x 100mm(w)
• Spare Partsn/a
• Switchdim3
• Type CommentsLED Linear Surface Mounted Luminaire
• Type NameLED Linear Surface Mounted Luminaire
• URLsynergy.gb.net/
• Warranty Descriptionn/a
• Warranty Duration Labor0
• Warranty Duration Parts0
• Warranty Duration UnitYear
• Warranty Guarantor Laborsales@synergy.gb.net
• Warranty Guarantor Partssales@synergy.gb.net
• Wattage Comments64W
• White Finish2
• Wire MaterialSynergy - Plastic - Black
