VR40S-MF NGCR MIFARE EV1 Reader + keypad

by ACRE International

Download Add to collection

Description

Modern attractive looking and hardwearing materials which endure the most challenging weather conditions. Multicolour programmable light frame on all readers which enhance the look and functionality of the reader. The customer can choose colours for each outcome and rest state.

Object Data

2 Revision

Last Updated

03/10/2022

Available Software

BS1192:4

Compliant

BSB

Compliant

EPD

Not Available

Accompanying literature

Object User Guide

Installation Guide

Product Literature

Product Data Sheet

Design Guide

Object metadata

_AuthorBS
_Authorized Bybimstore
_Bim Spec Guid0
_BS Bible Version16
_Created Bywww.bimstore.co/
_Current Revision1
_Distributed Bywww.bimstore.co/
_Object User Guidewww.bimstore.co/products/vanderbilt-vr40s-mf/document/object-user-guide
Accessibility Performancen/a
AccessoriesOptional Bluetooth add-on module. VR-BLE-SF BLE Module +Frame for VR10/40. V54504-Z105-A100
AdditionalMulticolour LED light frame. 3 x LED (red/yellow/green); 1 x Buzzer; Multicolor light frame. Auto dim in reduced light.
Air Humidity5-95% non-condensing
Anti Maskn/a
Assembly CodeD5030800
Asset TypeFixed
Audion/a
BIM Object NameVanderbilt_AccessControlReader_VR40SMF
Button MaterialPlastic, Opaque Black
Card Capacityn/a
Card CompatibilityMIFARE Classic; MIFARE Plus (UID only); MIFARE DESFire EV1; MIFARE DESFire EV2/EV3 (to EV1 conditions only)
Card Read DistanceUp to 6 cm
Card TechnologyMIFARE
Case MaterialPlastic, Opaque White
CategoryAccess Control Smart Card 13.56 MHz Readers
Classification NameUniclass2015
Classification ValuePr_75_30_30_03
Code Performancen/a
Collision Spacen/a
ColorBlack, matt chrome
Constituentsn/a
Created Bysupport.uk@vanderbiltindustries.com
Created On2022-07-28T09:00:00
Default Elevation0 mm
DescriptionModern attractive looking and hardwearing materials which endure the most challenging weather conditions. Multicolour programmable light frame on all readers which enhance the look and functionality of the reader. The customer can choose colours for each outcome and rest state.
Detection Characteristics Rangen/a
DisplayYes
Documentation Certificateswww.bimstore.co/products/vanderbilt-vr40s-mf/document/product-certificates
Documentation Installation Guidewww.bimstore.co/products/vanderbilt-vr40s-mf/document/installation-guide
Documentation Literaturewww.bimstore.co/products/vanderbilt-vr40s-mf/document/product-literature
Documentation Maintenancewww.bimstore.co/products/vanderbilt-vr40s-mf/document/maintenance-information
Documentation Technicalwww.bimstore.co/products/vanderbilt-vr40s-mf/document/technical-data-sheet
Door Capacityn/a
Duration UnitYears
Ean Upc Code4025515469841
Ecology CertificatesRoHS, REACH http://intranet.vanderbiltindustries.com/publish/Environmental_Compliance_Statement/Vanderbilt%20International%20-%20Environmental%20Compliance%20Statement%20-%2024-07-20.pdf
EnvironmentIndoor or outdoor use
EOL Resistorn/a
Expected Life0
FeaturesKey Features include: - Multicolour LED light frame - Auto dim in reduced light - Graphical OLED display - OSDP or Wiegand connectivity - MIFARE card technology including EV1 and EV2 - Hardwearing materials - IK class 08 and temperature range of -40°C to +70°C - Easy to mount and connect - Card reader only or card reader with keypad and/or display variants
Finishn/a
Graden/a
Housing ProtectionIP55 (surface mounted) IP3X (back box mounted) / IK08
Ifc Export AsIfcAlarm
Ifc Export TypeIfcAlarmType
IndicatorsLED, Graphic monochrome OLED
InterfaceRS485 OSDP
KeynoteW
LanguagesGerman, English, French, Spanish, Italian, Dutch, Czech, Danish, Greek, Finnish, Norwegian, Polish, Portuguese, Russian, Swedish
ManufacturerVanderbilt
Manufacturer NameVanderbilt
MaterialZinc casted metal bezel with polycarbonate plastic front
Metadatan/a
Microwaven/a
ModelVR40S-MF
Model NumberV54504-F102-A100
Model ReferenceVR40S-MF
MountingWall
NBS DescriptionAccess control units
NBS Noten/a
NBS Object NameVanderbilt - Access control units
NBS Office Master Tagn/a
NBS Reference90-75-05/430
Nominal Depth22 mm
Nominal Height114 mm
Nominal Length85 mm
Number Of On Board Relaysn/a
Number Of On Board Zonesn/a
Operating CurrentDC 12V = 60mA (220mA Peak); DC 24V = 40mA (125mA Peak)
Operating Temperature-40°C to +55°C (surface mounted) -10°C to +55°C (back box mounted)
Outputsn/a
Pet Immunityn/a
Production Year2022
Rangen/a
Referenced StandardCE (EU), EN (EU), UL (USA), SBSC (SE), (FI), EAR (Ru) Refer to: https://vanderbiltindustries.com/compliance-documents
RegionsWorldwide
Relay Outputsn/a
Replacement Costn/a
Screen MaterialGlass, Green
Sensitivity Evaluation Moden/a
ShapeRectangle
Size85mm(W) x 114mm(H) x 22mm(D)
Spare Partssupport.uk@vanderbiltindustries.com
Supply Voltage8.5 – 30.0 VDC
Tamper ProtectionYes
TitleVR40S-MF NGCR MIFARE EV1 Reader +keypad
Type CommentsV54504-F102-A100
Type NameV54504-F102-A100
URLvanderbiltindustries.com/
Verificationn/a
Videon/a
Walking Speedn/a
Warranty Descriptionn/a
Warranty Duration Labor0
Warranty Duration Parts10
Warranty Duration UnitYears
Warranty Guarantor Laborsupport.uk@vanderbiltindustries.com
Warranty Guarantor Partssupport.uk@vanderbiltindustries.com
Weight0.628kg

Sustainability & Environmental Data

Not available.

Environmental Product Declarations

There are no EPDs.
