VITM4-S - VITM6-S

by CP Electronics

Download Add to collection

Description

VITM4-S - VITM6-S - Electrical low mounted way-guidance lighting supply units.

Object Data

1 Revision

Last Updated

11/11/2019

Available Software

BS1192:4

Compliant

BSB

Compliant

EPD

Not Available

Accompanying literature

Product Data Sheet

Object metadata

_AuthorIan Holmes
_Authorized ByIan Holmes
_Bim Spec Guid0
_BS Bible Version15
_Created Bywww.bimstore.co.uk
_Current Revision1
_Distributed Bywww.bimstore.co.uk
Accessibility PerformanceAllow 150mm for total height of unit (including connectors)
Apparent Load0 VA
Assembly CodeD50
Asset TypeFixed
BIM Object NameCPElectronics_ElectricalEquipment_LightingStarterModule_(VITM4-S_VITM6-S)
Classification NameUniclass2015
Classification ValuePr_70_70_48_28
Code Performancen/a
ColorWhite RAL9003
Compliancen/a
Constituentsn/a
Created Byinfo@cpelectronics.co.uk
Created On2019-10-31T09:00:00
Default Elevation0 mm
DescriptionVitesse modular starter for non-dimming systems
Detector MaterialFlame Retardant ABS
Documentation Certificateswww.cpelectronics.co.uk/product-guides
Documentation Installation Guidewww.cpelectronics.co.uk/product-guides
Documentation Literaturewww.cpelectronics.co.uk/product-guides
Documentation Maintenancewww.cpelectronics.co.uk/product-guides
Documentation Technicalwww.cpelectronics.co.uk/product-guides
Duration UnitYears
Expected Life0
FeaturesStarter module, 4 pole, 4 outputs, black/grey coding
Finishn/a
Frequency50Hz
Graden/a
Humidity5 to 95% non-condensing
Ifc Export AsIfcJunctionBox
Ifc Export TypeIfcJunctionBoxTypeEnum.POWER
InsulationClass 2
IP Ratingn/a
KeynoteW41/320
Load0 A
ManufacturerCP Electronics
Manufacturer NameCP Electronics
MaterialFlame retardant ABS and PC/ABS
ModelStarter Module
Model NumberVITM4-S
Model ReferenceStarter Module
NBS DescriptionElectrical low mounted way-guidance lighting supply units
NBS Object NameCP Electronics - Electrical low mounted way-guidance lighting supply units
NBS Office Master Tagn/a
NBS Reference90-60-50/485
Nominal Depth147 mm
Nominal Height52 mm
Nominal Length202 mm
Power Consumption Off0mW
Power Consumption On0mW
Production Year2019
PurposeOperating control
Rating Of Outputs10A
Rating Of System16A
Referenced StandardBS 5733:1995
Replacement Costn/a
ShapeRectangle
Sizen/a
Spare Partsn/a
Temperature Range0°C to + 35°C
Terminal Capacity4mm2
Type CommentsVITM4-S
Type NameVITM4-S
URLwww.cpelectronics.co.uk/
Voltage230.00 V
Warranty Descriptionn/a
Warranty Duration Labor5
Warranty Duration Parts5
Warranty Duration UnitYears
Warranty Guarantor Laborinfo@cpelectronics.co.uk
Warranty Guarantor Partsinfo@cpelectronics.co.uk
Weight1.00 kg

Sustainability & Environmental Data

Not available.

Environmental Product Declarations

There are no EPDs.
