Wind Posts

by Expamet

Download Add to collection

Description

Custom, bespoke wind post solutions can be made to order direct from Expamet. The wind posts downloadable are place holder reference objects only and should be used as such. Posts are manufactured to BS EN 1090-1:2009+A1:2011 and can be galvanized upon request to BS EN ISO 1461:2009.

Object Data

1 Revision

Last Updated

03/05/2019

Available Software

BS1192:4

Compliant

BSB

Compliant

EPD

Not Available

Accompanying literature

Object User Guide

Product Data Sheet

Object metadata

_AuthorCL
_Authorized ByRW
_Bim Spec Guid0
_BS Bible Version16
_Created Bywww.bimstore.co.uk
_Current Revision1
_Distributed Bywww.bimstore.co.uk
Accessibility Performancen/a
Assembly CodeB
Asset TypeFixed
BIM Object NameExpamet_MasonrySuports_WindPost_140x70x4
Classification NameUniclass2015
Classification ValuePr_20_85_03_50
Code Performancen/a
ColorStainless Steel
Constituentsn/a
Created Byinfo@birtleygroup.co.uk
Created On2018-12-01T09:00:00
Depth80 mm
DescriptionBespoke made-to-order Masonry Suppport systems – can be supplied in a variety of configurations to suit load and application.
Documentation Certificatesn/a
Documentation Installation Guiden/a
Documentation Literaturen/a
Documentation Maintenancen/a
Documentation Technicaln/a
Duration UnitYears
Expected Life0
External Radius8 mm
FeaturesBespoke design to suit cavity and load
FinishStainless Steel
GradeGrade 304
Ifc Export AsIfcBeam
Ifc Export TypeIfcBeamTypeEnum.LINTEL
Internal Radius4 mm
KeynoteL
Leaf Tie95 mm
ManufacturerExpamet
Manufacturer NameExpamet
MaterialStainless Steel
ModelWind Post - 140x70x4mm
Model NumberWind Post - 140x70x4mm
Model ReferenceWind Post - 140x70x4mm
NBS DescriptionMasonry supports
NBS Object NameExpamet; Masonry supports
NBS Reference45-25-95/410
Nominal Depth0 mm
Nominal Height0 mm
Nominal Length0 mm
Production Year2019
Referenced Standardn/a
Replacement Costn/a
Section Depth165 mm
Section Space10 mm
Section Thickness4 mm
Section Width135 mm
ShapeRectangle
Sizen/a
Spare Partsn/a
Thickness4 mm
Type CommentsWind Post - 140x70x4mm
Type NameWind Post - 140x70x4mm
URLwww.expamet.co.uk/
Warranty Descriptionn/a
Warranty Duration Labor0
Warranty Duration Parts0
Warranty Duration UnitYears
Warranty Guarantor Laborinfo@birtleygroup.co.uk
Warranty Guarantor Partsinfo@birtleygroup.co.uk
Width60 mm
