Cavity Trays Ltd BIM components now live on bimstore
What’s new on bimstore?
Time to introduce another new manufacturer who has chosen to have their BIM components created and hosted by the bimstore team – the UK’s original BIM library.
Say hello to Cavity Trays!
Cavity Trays Ltdmanufacture an extensive range of pre-formed trays, flashings, membranes, barriers, DPC’s, closers and associated products. They are the first and only tray manufacturer awarded European Technical Approval - there is no higher standard! Cavitrays with high-performance categorisation are accompanied with product performance liability, for the benefit of Architect, Builder and Client.
Now on bimstore, there are five new product listings live for Cavity Trays Ltd Revit BIM components, as follows;Type BWVC Cavitrays -The Type BWVC is a pre-formed DPC cavitray that vertically connects two levels within the same masonry skin without adversely interrupting bonding or coursing. Its presence prevents horizontal damp transference. It is extensively used in bay window construction where the level of the roof intersection and that of the support lintel spanning the bay is not shared and separating courses exist between them.
Type C Cavitrays - Type C cavitrays provide a harmonising yet independent DPC tray for all lintel openings. Manufactured from solid DPC, Type C cavitrays are pre-shaped to suit customer’s specific construction needs. Being pre-shaped means the installer establishes exactly what is being built into the cavity wall, whilst eliminating the dangers of distortion and misplacement.Type E Cavitrays – The Type E is a preformed DPC cavitray which is inserted into an existing cavity wall. The Type E requires only one course of bricks to be disturbed, with just a few bricks removed at any time. The self-contained Type E cavitrays are the length of two bricks, and clip together, so long runs are easily and quickly created. Preformed angles cater for corners and piers. Each unit has stand-alone discharge via a weep. Suitable for all popular cavity widths because the cavity upstand of the Type E is hinged and adjusts to always suit the ‘as-found’ cavity width.
Type G Cavitrays - Type G Cavitray is available with an attached lead flashing (example 300mm.) In this example, the flashing is sufficient to dress directly over the abutting roof tiles.
Type X Cavitrays -The Type X Cavitray is a preformed DPC unit with an attached ready-shaped flashing. When laid in every course of a cavity wall external skin against which a sloping roof abuts, trays provide continuous stepped DPC protection running parallel with the slope. Water and dampness in the exposed masonry skin above this stepped arrangement are prevented from gravitating downwardly below it. Thus the masonry skin is wet above the roofline but remains dry where it becomes an internal wall.
The downloads are a 2D detail component created by bimstore.co.uk for Cavity Trays in Revit 2014 and in line with industry standards.
Visit the Cavity Trays Ltd manufacturer page on bimstore now to view their full range of Revit BIM content.
