ESSENCE E Infra-Red Electronic Basin Mixer (36445A00)

by GROHE

Download Add to collection

Description

Product Number - 36445A00

EAN - 4005176686795

Colour - hard graphite

PRODUCT MAIN FEATURES

with infrared sensor for bi-directional communication for monitoring, configuration and servicing
6V lithium battery, type CR-P2
battery lifetime approx. 7 years (150 actuations a day)
GROHE Long-Life finish
GROHE Water Saving - Less water, perfect flow
maximum flow rate (at 3 bar): 5 l/min
adjustable swivel area 0° / 150° / 360°
laminar spray regulator
flexible connection hoses
non-return valve
dirt strainers
with integrated solenoid valve
external battery
rapid installation system
multistage battery status display
7 pre-set programs
auto flush
thermal disinfection
cleaning mode
additional functions and precise settings by remote control 36 407
CE approved
noise classification 1 in accordance with DIN4109
type of protection faucet IP 59K

Product Page - https://www.grohe.co.uk/en_gb/essence-e-infra-red-electronic-basin-mixer-1-2-with-mixing-device-and-adjustable-temperature-limiter-36445A00.html

Object Data

1 Revision

Last Updated

14/10/2024

Available Software

BS1192:4

Compliant

BSB

Compliant

EPD

Not Available

Accompanying literature

Object User Guide

Product Data Sheet

Object metadata

_AuthorSM 192
_Authorized Bybimstore
_Bim Spec Guid0
_BS Bible Version17
_Created Bywww.bimstore.co/
_Current Revision1
_Distributed Bywww.bimstore.co/
_Object User Guidewww.bimstore.co/products/euro-eco-single-lever-mixer-36445A00/document/object-user-guide
Accessibility Performancen/a
Assembly CodeD2010
Asset TypeFixed
BIM Object NameGrohe_SingleLeverMixer_Euroeco_36445A00
Classification NameUniclass2015
Classification ValuePr_40_20_87_55
CO2 Neutral ProductionGROHE is one of the first leading manufacturer within the sanitary industry having a CO2-neutral production.
Code Performancen/a
ColorHard Graphite
Constituentsn/a
Cradle To Cradle CertificationN/A
Created Byinfo-uk@grohe.com
Created On2024-10-14T:09:00:00
CW ConnectionYes
Default Elevation0 mm
Descriptionwith infrared sensor for bi-directional communication for monitoring, configuration and servicing 6 V lithium battery, type CR-P2 battery lifetime: approx. 7 years (150 actuations a day) GROHE Long-Life finish GROHE Water Saving - Less water, perfect flow maximum flow rate (at 3 bar): 5 l/min adjustable swivel area 0° / 150° / 360° laminar spray regulator flexible connection hoses non-return valve dirt strainers with integrated solenoid valve external battery rapid installation system multistage battery status display 7 pre-set programs: auto flush thermal disinfection cleaning mode additional functions and precise settings by remote control 36 407 CE approved noise classification I in accordance with DIN 4109 type of protection faucet IP 59K min. recommended pressure 1.0 bar
Dimensions Document Linkcdn.cloud.grohe.com/dimdraw/2000/2100/2100/2101/2101768/1280/2101768.jpg
Documentation Certificateswww.bimstore.co/products/euro-eco-single-lever-mixer-36445A00/document/product-certificates
Documentation Installation Guidewww.bimstore.co/products/euro-eco-single-lever-mixer-36445A00/document/installation-guide
Documentation Literaturewww.bimstore.co/products/euro-eco-single-lever-mixer-36445A00/document/product-literature
Documentation Maintenancewww.bimstore.co/products/euro-eco-single-lever-mixer-36445A00/document/maintenance-information
Documentation Technicalwww.bimstore.co/products/euro-eco-single-lever-mixer-36445A00/document/technical-data-sheet
Duration UnitYears
EcojoyNo
EF000003Top/tap hole
EF000139Other
EF000278false
EF0003320
EF000958false
EF001469Battery
EF00170770 °C
EF002149TRUE
EF002286Hose (gland nut)
EF002671Other
EF0036256
EF0041210
EF0054640
EF005474IP59K
EF006013true
EF006974Manually operated
EF007955FALSE
EF011775EB
EF011779FALSE
EF011781not applicable
EF012635true
EF012637false
EF0127535.00
EF014578not applicable
EF014591true
EF015280not relevant
EF016731Group I,<= 20 dB(A)
EF020075Yes
EF020103not relevant
EF020105Yes
EF020776false
EF020779false
EF020780Single-grip
EF020781Plastic cartridge
EF0207853/8 inch
EF020787Group I,<= 20 dB(A)
EF020788true
EF020789127
EF020791Brass
EF020792FALSE
EF020794FALSE
EF020795Fixed, bottom
EF020796245 mm
EF020797211
EF020798Pop-up waste (click-clack)
EF020799TRUE
EF020800false
EF020801FALSE
EF020825false
EF020826true
EF020871false
EF020872false
EF020873false
EF020966false
EF021720true
EF0218081-hole
EF0218275.0
EF0218350
EF021836false
EF022042None
EF022117Infrared
EF022133false
EF022168TRUE
EF0222320
EF022750Cast
EF023686not applicable
EF023687TRUE
EF023688Anti-splash jet nozzle
EF023957FALSE
EF024921true
EF0249224
EF025098true
EF02509930
EF025101not relevant
EF025102Remote control
EF025104TRUE
EF025109Brushed
EF025247false
EFDE0022None
EFNL0001false
EFSE0002false
Expected Life0
Featuresn/a
FinishHard Graphite
Full Recyclability Of PlasticAll plastic components are fully recycable
Graden/a
GROHE Social Committmentgreen.grohe.com/social_engagement
GROHE Sustainabilitygreen.grohe.com
HW ConnectionYes
Ifc Export AsIfcPipeFitting
Ifc Export TypeIfcPipeFittingType
Installation Videon/a
KeynoteN13
ManufacturerGrohe
Manufacturer NameGrohe
Materialn/a
ModelESSENCE E Basin Mixer 36445A00
Model Number36445A00
Model ReferenceESSENCE E Basin Mixer 36445A00
NBS DescriptionTaps and water supply fittings for sinks
NBS Noten/a
NBS Object NameGrohe - Taps and water supply fittings for sinks
NBS Office Master Tagn/a
NBS Reference45-35-70/345
Nominal Depth0 mm
Nominal Height0 mm
Nominal Length0 mm
PQ Diagram Linkcdn.cloud.grohe.com/PQCharts/lores/3/364/original/36445A00-pqchart-en_GB.svg
Primary MaterialGrohe_HardGraphite
Product Descriptionwith infrared sensor for bi-directional communication for monitoring, configuration and servicing 6 V lithium battery, type CR-P2 battery lifetime: approx. 7 years (150 actuations a day) GROHE Long-Life finish GROHE Water Saving - Less water, perfect flow maximum flow rate (at 3 bar): 5 l/min adjustable swivel area 0° / 150° / 360° laminar spray regulator flexible connection hoses non-return valve dirt strainers with integrated solenoid valve external battery rapid installation system multistage battery status display 7 pre-set programs: auto flush thermal disinfection cleaning mode additional functions and precise settings by remote control 36 407 CE approved noise classification I in accordance with DIN 4109 type of protection faucet IP 59K min. recommended pressure 1.0 bar
Production Year2024
Product Number36445A00
Product Short TextInfra-red electronic basin mixer 1/2" with mixing device and adjustable temperature limiter
Product TypeSingle Lever Mixer
Referenced Standardn/a
Replacement Costn/a
Shapen/a
Sizen/a
Spare Partsinfo-uk@grohe.com
Sustainability Awardgreen.grohe.com/awards
Sustainability Reportgreen.grohe.com/reporting
TPI Document Linkcdn.cloud.grohe.com/tpi/2000/2100/2190/2197/2197354/original/2197354.pdf cdn.cloud.grohe.com/tpi/2000/2200/2200/2205/2205752/original/2205752.pdf cdn.cloud.grohe.com/tpi/2000/2100/2170/2171/2171304/original/2171304.pdf cdn.cloud.grohe.com/tpi/100000/100000/100000/100200/100240/100240/100240533/original/100240533.pdf cdn.cloud.grohe.com/tpi/100000/100000/100000/100200/100230/100232/100232020/original/100232020.pdf cdn.cloud.grohe.com/tpi/100000/100000/100000/100100/100120/100129/100129724/original/100129724.pdf cdn.cloud.grohe.com/tpi/1000/1800/1890/1895/1895303/original/1895303.pdf
Type CommentsESSENCE E Basin Mixer 36445A00
Type NameESSENCE E Basin Mixer (36445A00)
URLwww.grohe.co.uk/
Vent ConnectionNo
Warranty Descriptionn/a
Warranty Duration Labor0
Warranty Duration Parts0
Warranty Duration UnitYears
Warranty Guarantor Laborinfo-uk@grohe.com
Warranty Guarantor Partsinfo-uk@grohe.com
Waste ConnectionNo
