Maxwall HTM Ducting System

Object metadata

• _AuthorAM
• _Authorized Bybimstore
• _Bim Spec Guid0
• _BS Bible Version16
• _Created Bywww.bimstore.co
• _Current Revision1
• _Distributed Bywww.bimstore.co
• _Object User Guidewww.bimstore.co/products/maxwall-htm-ducting-system/document/object-user-guide
• Accessibility Performancen/a
• Assembly CodeE1020810
• Asset TypeFixed
• Base Panel Height250.0 mm
• Base Panel Offset25.0 mm
• BIM Object NameMaxwoodWashrooms_DuctLinings_MaxwallHTM
• Bracket Offset Bottom70.0 mm
• Bracket Offset Top50.0 mm
• Classification NameUniclass2015
• Classification ValuePr_40_20_93_86
• Code Performancen/a
• Colorn/a
• Constituentsn/a
• Created Byinspired@maxwoodwashrooms.com
• Created On2020-07-21 T09:00:00
• Crossbeam 1 Height1200.0 mm
• Crossbeam 2 Height2000.0 mm
• DescriptionPractical and pleasing to the eye, Maxwall gives the finishing touch to any washroom, neatly concealing pipework and cisterns whilst uniting all the design elements. It has a well deserved reputation for simplicity, flexibility and exceptional ease of installation. A reliable and straightforward ducting system which also benefits from an outstanding range of premium finishes.
• Documentation Certificateswww.bimstore.co/products/maxwall-htm-ducting-system/document/product-certificates
• Documentation Installation Guidewww.bimstore.co/products/maxwall-htm-ducting-system/document/installation-guide
• Documentation Literaturewww.bimstore.co/products/maxwall-htm-ducting-system/document/product-literature
• Documentation Maintenancewww.bimstore.co/products/maxwall-htm-ducting-system/document/maintenance-information
• Documentation Technicalwww.bimstore.co/products/maxwall-htm-ducting-system/document/technical-data-sheet
• Duration UnitYear
• Expected Life0
• FeaturesWide range of colours available to suit any look & feel - other highly bespoke finishes available on request; Flexibilty - made to measure and your design; Rapid installation due to modular kit-of-parts configuration; pre-finished shadows prevent any on site laminating; Precision - All panels supplied pre-hung on factory-assembled alumnium frames; Easy to maintain and sanitise; Sanitaryware support rails factory-fitted.
• FinishSee Element Materials
• Flash Gap Width5.0 mm
• Frame Header Section Height200.0 mm
• Frame MaterialMaxwood - Finish - Cubicle - Amethyst
• Frame Starter Section Width75.0 mm
• Frame Thickness25.0 mm
• Graden/a
• Head Panel Downstand100.0 mm
• Head Panel Offset75.0 mm
• Ifc Export AsIfcDuctLining
• Ifc Export TypeIfcDuctLiningType
• KeynoteK32/160
• LHS End PanelNo
• ManufacturerMaxwood Washrooms Ltd
• Manufacturer NameMaxwood Washrooms Ltd
• Materialn/a
• Mid Panel Height900.0 mm
• ModelMaxwall HTM
• Model NumberMaxwall HTM
• Model ReferenceIntermediate Duct Panel Set
• NBS Description45-35-70/410
• NBS Noten/a
• NBS Object NameMaxwood Washrooms - Duct Lining - Panels and Proprietary Frames
• NBS Office Master Tagn/a
• NBS ReferenceDuct Lining - Panels and Proprietary Frames
• Nominal Depth0.0 mm
• Nominal Height0.0 mm
• Nominal Length0.0 mm
• Panel Bracket Offset18.0 mm
• Panel Gap2.0 mm
• Panel MaterialMaxwood - Finish - Cubicle - Amethyst
• Panel Side Offset70.0 mm
• Panel Thickness20.0 mm
• Panel TypeHPL (High Pressure Laminate)
• Plinth Height100.0 mm
• Production Year2021
• Referenced Standardn/a
• Replacement Cost0
• RHS End PanelNo
• ShapeRectangular
• Sizen/a
• Spare Partsn/a
• Top Of Pattress452.5 mm
• Type CommentsIntermediate Duct Panel Set
• Type NameIntermediate Duct Panel Set
• URLwww.maxwoodwashrooms.com/duct-pannelling
• Warranty Descriptionn/a
• Warranty Duration Labor0
• Warranty Duration Parts0
• Warranty Duration UnitYear
• Warranty Guarantor Laborinspired@maxwoodwashrooms.com
• Warranty Guarantor Partsinspired@maxwoodwashrooms.com
