315i Series Pressure Reducing Valve PRV

Object metadata

• _BIMspec_GUID0
• _created byMark Thompson
• _current revision1
• _distributed bywww.bimstore.co.uk
• 90 Deg Radius7 mm
• 90 Radius Offset9 mm
• A mm130 mm
• Adjustable Set Pressure1.5-6.0 bar
• Assembly CodeD2090800
• Asset TypeFixed
• B mm74 mm
• Bar Code5036124112096
• BodyDZR Brass - Reliance
• Body Height34 mm
• Body Radius15 mm
• C mm103 mm
• Centre Bottom Flat Radius8 mm
• Centre Bottom Radius23 mm
• Centre Disk Height11 mm
• Centre Disk Radius24 mm
• Centre Height11 mm
• Classification NameUniclass1.4
• Classification ValueL7136
• CodePRED315010
• CoverABS - Reliance
• Created Bytechnical@rwc.co.uk
• Created OnFeb 2015
• D mm15 mm
• D Radius8 mm
• DescriptionA range of commercial pressure reducing valves, incorporating a unique indicator so the set pressure can be identified easily without the need for a pressure gauge
• DiaphragmEPDM
• Documentation CertificatesWRAS
• Documentation Literaturewww.rwc.co.uk/images/pdfs/prv/PRV_001.pdf
• Documentation Technicalwww.rwc.co.uk/images/pdfs/prv/PRV_001.pdf
• Duration UnitYears
• Expected Life25
• FeaturesEasy-to-read dial up pressure indicator, one piece cartridge, fully serviceable strainer, suitable for hot and cold supplies
• FinishSelf colour brass
• Hex Depth37 mm
• Hex Diameter35 mm
• Hex Hex Depth15 mm
• Indicator Height58 mm
• Indicator Radius18 mm
• Internal ComponentsDZR Brass - Reliance
• K Coefficient0
• KeynoteS10
• l mm72 mm
• ManufacturerReliance Water Controls
• MaterialDezinctification Resistant Brass
• Maximum Temperature70 °C
• Maximum Working Pressure2500000.0 Pa
• Model315i Commercial Pressure Reducing Valve
• Model NumberPRED315010
• Pressure Reduction Ratio10:1
• Product Page Linkwww.rwc.co.uk/products/pressure-reducing-valves/105-315i-series-commercial-pressure-reducing-valves
• Production Year2015
• Referenced StandardBS EN 1567
• SealsEPDM
• Size1/2"
• StrainerStainless Steel - Reliance
• Threaded MaterialBrass, Soft YellowThread
• Type Comments1/2 MBSP Adj 1.5-6.0bar 315i PRV
• Type No1
• Type NamePRED315010
• Uniclass 2Pr_65_54_95_66
• URLwww.rwc.co.uk/
• Warranty Duration Parts2
• Warranty Duration UnitYears
