Reduced Bore – FIG LN190 1 pce 1000WO [Ball Valves]

Object metadata

• _Authorbimstore
• _Authorized ByKA
• _Bim Spec Guid0
• _BS Bible Version14
• _Created Bywww.bimstore.co.uk
• _Current Revision1
• _Distributed Bywww.bimstore.co.uk
• A_mm82.800000000000 mm
• Accessibility Performancen/a
• Assembly CodeD30
• Asset TypeFixed
• B_mm71.100000000000 mm
• BallASTM A351-CF8/304
• Belleville WasherAISI301
• BIM Object NameBOSS_PipeAccessory_BallValve_LN190
• BodyASTMA216-WCB
• bodyoffset 115.000000000000 mm
• bodyoffset 20.000000000000 mm
• bodyoffset 316.000000000000 mm
• bodyradius 124.000000000000 mm
• bodyradius 223.000000000000 mm
• bodyradius 324.000000000000 mm
• Brake Downstand12.000000000000 mm
• C_mm133.000000000000 mm
• Classification NameUniclass 2015
• Classification ValuePr_65_54_95_06
• Code Performancen/a
• ColorCarbon Steel - Blue
• ConnectionsScrewed BSPT Female
• Connection Size40.000000000000 mm
• Constituentsn/a
• Created Byenquiries@bssgroup.com
• Created On1900-12-31T23:59:59
• DescriptionCarbon Steel Full Bore - LN190 Ball Valve
• Dim X8.000000000000 mm
• Dim XX10.000000000000 mm
• Documentation Certificatesn/a
• Documentation Installation Guiden/a
• Documentation Literaturespecifi.bimstore.co.uk/document/share/2079
• Documentation Maintenancen/a
• Documentation Technicaln/a
• Duration UnitYears
• Expected Life0
• FeaturesCarbon Steel Full Bore - LN190 Ball Valve
• FinishBlue
• Flow0.000000000000 L/s
• GasketPTFE
• Graden/a
• HandleAISI304
• Handle Calc13.500000000000 mm
• Handle Collar Length30.000000000000 mm
• Handle CoverPVC
• Handle Downstand28.900000000000 mm
• Handle Length100.000000000000 mm
• Handle MaterialBOSS_Blue
• Handle NutZinc Plated Steel
• Handle WasherAISI304
• Handle Width27.000000000000 mm
• Ifc Export AsIfcValve
• Ifc Export TypeIfcValveTypeEnum.STOPCOCK
• K Coefficient96
• KeynoteS
• L1 mm21.500000000000 mm
• Loss Method2
• ManufacturerBOSS
• Manufacturer NameBOSS
• MaterialCarbon Steel
• Model36420270
• Model Number36420270
• Model ReferenceCarbon Steel Full Bore - LN190 Ball Valve
• NBS DescriptionBall stop valves
• NBS Noten/a
• NBS Object NameBOSS - Ball stop valves
• NBS Office Master Tagn/a
• NBS Reference90-20-80/325
• Nominal Depth0.000000000000 mm
• Nominal Height71.100000000000 mm
• Nominal Length82.800000000000 mm
• Pressure Rating10.5bar @ 180
• Product Code36420270
• Production Year2017
• Referenced Standardn/a
• Replacement Costn/a
• SeatsPTFE
• Shapen/a
• Size42mm
• Size mm20.000000000000 mm
• Spare Partsn/a
• StemASTM A276-304
• Stem Height48.000000000000 mm
• Stem MaterialBOSS_StainlessSteel
• Stem PackingPTFE
• Stem Rad12.000000000000 mm
• Stem Top Rad13.000000000000 mm
• Swing ZoneBOSS-SWINGZONE
• Thrust WasherPTFE
• Type Comments42mm
• Type NameCarbon Steel Full Bore - LN190 Ball Valve
• URLwww.bssindustrial.co.uk/Product-Centre/Valves-Filtration
• Valve Hax Calc 250.000000000000 mm
• Valve Hex Calc48.000000000000 mm
• Valve MaterialBOSS_CastIron
• Warranty Descriptionn/a
• Warranty Duration Laborn/a
• Warranty Duration Partsn/a
• Warranty Duration UnitYears
• Warranty Guarantor Laborn/a
• Warranty Guarantor Partsn/a
• Weight_Kg0.864
