ART 675 - Pressure Reducing Valve with gauge

Object metadata

• _AuthorRL
• _Authorized Bybimstore
• _Bim Spec Guid0
• _BS Bible Version16
• _Created Bywww.bimstore.co
• _Current Revision1
• _Distributed Bywww.bimstore.co
• _Object User Guidewww.bimstore.co/products/art-675-pressure-reducing-valve-with-gauge/document/object-user-guide
• Accessibility Performancen/a
• Adjustable Pressure Range1 - 6 Bar
• Assembly CodeD20
• Asset TypeFixed
• B93 mm
• BIM Object NameAlbionValves_PipeAccessories_PressureReducing_ART675
• C53 mm
• Classification NameUniclass2015
• Classification ValuePr_65_54_95_66
• Code Performancen/a
• ColorSilver
• Connection Size15 mm
• Constituentsn/a
• Created Bysales@albionvalvesuk.com
• Created On2020-08-19T09:00:00
• D6 mm
• DescriptionPressure Reducing Valve with gauge
• Documentation Certificateswww.albionvalvesuk.com/
• Documentation Installation Guidewww.albionvalvesuk.com/
• Documentation Literaturewww.albionvalvesuk.com/
• Documentation Maintenancewww.albionvalvesuk.com/
• Documentation Technicalwww.bimstore.co/products/art-675-pressure-reducing-valve-with-gauge/document/technical-data-sheet
• Duration UnitYears
• Expected Life0
• External Diameter27 mm
• Factory Set Pressure3 Bar
• Featuresn/a
• FinishBrass
• Graden/a
• Ifc Export AsIfcValve
• Ifc Export TypeIfcValveTypeEnum.CHECK
• Internal Diameter22 mm
• KeynoteS
• L104 mm
• L189 mm
• ManufacturerAlbion Valves
• Manufacturer NameAlbion Valves
• MaterialDZR - CW602N
• Maximum Inlet Pressure(Static)16 Bar
• Maximum Inlet Temperature80°C
• Minimum Inlet Pressure1 Bar
• ModelPressure Reducing Valve with gauge
• Model NumberDN15
• Model ReferencePressure Reducing Valve with gauge
• N13 mm
• N28 mm
• NBS DescriptionPressure reducing valves
• NBS Object NameAlbion Valves - Pressure reducing valves
• NBS Office Master Tagn/a
• NBS Reference90-10-90/410
• Nominal Depth48 mm
• Nominal Height93 mm
• Nominal Length123 mm
• Nut Size32 mm
• Pressure Gauge0 - 10 Bar
• Production Year2020
• Reducer Length9 mm
• ReducersYes
• Referenced Standardn/a
• Replacement Costn/a
• Shapen/a
• SizeDN15
• Size DN15
• Socket Depth 19 mm
• Socket Depth 29 mm
• Spare Partsn/a
• Thread Inch1/2
• Thread Millimetre15 mm
• Type CommentsDN15
• Type NamePressure Reducing Valve with gauge
• URLwww.albionvalvesuk.com/
• Valve FinishDZR Brass - Chrome Plated
• Valve Finish 2Plastic - Black
• Warranty DescriptionAgainst manufacturing defects.
• Warranty Duration Labor1
• Warranty Duration Parts1
• Warranty Duration UnitYears
• Warranty Guarantor Laborsales@albionvalvesuk.com
• Warranty Guarantor Partssales@albionvalvesuk.com
• Weight0.61 kg
• Working Temperature-20°C to +80°C
